Honeywell 3800i – Barcode Scanner – Corded – 1D

Part Number: 3800ISR030E
Model: 3800i
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Handheld
Interface Options
Serial
Scanner Capability
1D

Product Description:

  SCANNER ONLY, True RS-232 (NOT A STANDARD CONFIGURATION). Cables and accessories are not included and must be purchased separately. These include RS-232 Serial cables (Part# 42203758-03E) and a Power supply (Part# PS-090-2000D-NA). Non-Cancelable/Non-Returnable.
Explore all Honeywell 3800i Barcode Scanners
Add to Quote
Honeywell 3800ISR030E Barcode Scanner
Honeywell 3800ISR030E Barcode Scanner
Honeywell 3800ISR030E Barcode Scanner
Honeywell 3800ISR030E Barcode Scanner Honeywell 3800ISR030E Barcode Scanner Honeywell 3800ISR030E Barcode Scanner
Full specifications (PDF)

Honeywell 3800i Barcode Scanner Model Overview

The 3800i handheld industrial image readers are the first industrial class readers to bring you Honeywell industry-leading image technology. This technology allows you to read barcodes at ranges up to 82 inches (208 cm). In real world applications, this extended read range means less climbing and reaching, and more operator productivity.
Honeywell 3800ISR030E Barcode Scanner Overview

The 3800i handheld industrial image readers are the first industrial class readers to bring you Hand HeldProducts industry-leading image technology. This technology allows you to read bar codes at ranges upto 82" (208 cm). In real world applications, this extended read range means less climbing andreaching, and more operator productivity.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • Codabar
  • Code 39 including PARAF
  • Interleaved 2 of 5
  • Code 2 of 5
  • Matrix 2 of 5
  • Code 11
  • Code 93
  • Code 128
  • UPC
  • EAN/JAN
  • China Post
  • RSS
  • and ISBT 128 Concatenation (requires a paid license)
Light Source:
LED
Image Sensor Type:
Linear
Scan Rate:
270 scan/s
Maximum Scan Resolution:
7.50 mil
Depth of Field:
  • 6.5" - 15"@7.5mil
  • 2.5" - 28"@100% UPC
  • 2.5" - 31"@15mil
  • 1.5" - 42"@20mil
  • 4" - 82"@55mil
Scan Pattern:
Linear
Scanning Distance:
82"
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
14 V DC
Physical Characteristics
Form Factor:
Handheld
Product Color:
Orange
Height:
6.4"
Width:
3.2"
Depth:
5.3"
Weight (Approximate):
7.50 oz
Miscellaneous
Additional Information:

Supported Interfaces:

  • Serial
  • Keyboard Wedge
  • USB
  • Wand Emulation
  • HHLC Non-decoded Laser Compatible
  • IBM 468X/469X
  • TTL level RS-232

    • Platform Supported:
    PC
    Certifications & Standards:
    • FCC Class B
    • CE EMC Class B
    • CE Low Voltage Directive
    • UL
    • cUL
    • TÜV
    • RoHS
    Environmentally Friendly:
    Yes
    Warranty
    Limited Warranty:
    3 Year
    Item Numbers
    UNSPSC: 43211701
