Honeywell 3800g – Barcode Scanner – 1D

Part Number: 3800G04-SERKIT3E
Model: 3800g
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Scanner Capability
1D
Scanner Type
Imager

Product Description:

  UK RS-232 kit, 1D Linear Imager. Includes RS-232 cable and UK power supply. Color: White.
Explore all Honeywell 3800g Barcode Scanners
Add to Quote
Honeywell 3800G04-SERKIT3E Barcode Scanner
Honeywell 3800G04-SERKIT3E Barcode Scanner
Honeywell 3800G04-SERKIT3E Barcode Scanner
Honeywell 3800G04-SERKIT3E Barcode Scanner Honeywell 3800G04-SERKIT3E Barcode Scanner Honeywell 3800G04-SERKIT3E Barcode Scanner
Full specifications (PDF)

Honeywell 3800g Barcode Scanner Model Overview

The 3800g is built to deliver world-class performance for a broad range of applications in retail, manufacturing, warehousing, distribution and all points in between. Featuring the ideal balance of performance, durability, ergonomics and connectivity options, the 3800g will deliver years of hassle-free service. The 3800g features improved depth of field, fast barcode reading and high tolerance to motion, plus a convenient variety of connectivity options, including USB, PS/2 Keyboard Wedge and RS232 Serial.
Honeywell 3800G04-SERKIT3E Barcode Scanner Overview

The first linear imager 3800g Bar Code Reader to earn the Adaptus Imaging Technology brand, the new 3800g is powered by Adaptus 5.0, delivering breakthrough linear imaging performance and versatility. Fast, intuitive bar code reading across a range of high and low density codes, the 3800g quickly reads even damaged and poorly printed bar codes all in a single device.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
  • Codabar
  • Code 3 of 9 including PARAF
  • Interleaved 2 of 5
  • Straight 2 of 5 Industrial
  • Matrix 2 of 5
  • Code 11
  • Code 93
  • Code 128
  • UPC
  • EAN/JAN
  • China Postal Code
  • GS1 DataBar
Light Source:
LED
Image Sensor Type:
Imager
Scan Rate:
270 scan/s
Maximum Scan Resolution:
3 mil
Depth of Field:
  • 2" - 8"@5mil
  • 1.5" - 12"@7.5mil
  • 1" - 15"@10mil - 80% UPC
  • 0.5" - 18"@13mil - 100% UPC
  • 1" - 22"@15mil
  • 1" - 26"@20mil
Scan Pattern:
Linear
Cable Type Included:
Serial
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5 V DC
Power Supply Included:
Yes
Physical Characteristics
Form Factor:
Handheld
Product Color:
Ivory
Height:
5.9"
Width:
3.1"
Depth:
4.4"
Weight (Approximate):
5.60 oz
Miscellaneous
Package Contents:
  • 3800g Bar Code Reader
  • Straight RS-232 Cable
  • Quick Start Guide
  • Power Supply
  • UK Power Cord
Additional Information:

Supported Interfaces:

  • USB
  • TTL level RS-232

USB Cable separate

Certifications & Standards:
  • FCC Class B
  • CE EMC Class B
  • CE Low Voltage Directive
  • IEC60825-1 LED Safety: Class 1
  • UL
  • cUL listed
  • RoHS
Warranty
Limited Warranty:
5 Year
Item Numbers
UNSPSC: 43211701
