The Honeywell Vuquest™ 3320g is a compact area-imaging scanner designed to provide superior scanning performance for all types of barcodes, including 1D, PDF, and 2D formats. Lightweight and durable, this scanner blends seamlessly into any retail environment while offering advanced capabilities powered by Adaptus™ Imaging Technology 6.0. Its unobtrusive illumination minimizes distractions, ensuring a user-friendly experience. Equipped with the Total Freedom™ 2.0 development platform, the Vuquest 3320g enhances functionality by allowing custom decoding and formatting plug-ins, catering to unique business requirements.
Key features:
Intelligent multi-interface design: Automates interface detection and supports various connections.
Direct scanning from screens: Scans barcodes from mobile devices with ease.
Laser-free aiming: Provides accurate scanning without risk of eye injury.
Flexible licensing solution: Upgrade scanning capabilities as needed with simple license purchases.
Specifications:
Dimensions: 73 mm x 51 mm x 26 mm (2.9 in x 2.0 in x 1.0 in)
Weight: 77 g (2.7 oz)
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Humidity: 5% to 95% relative humidity, non-condensing
Drop Resistance: Designed to withstand drops of up to 1.5 m (5 ft)
IP Rating: IP53 for environmental sealing
Decode Capability: Reads standard 1D, 2D, Postal and OCR symbologies
Warranty: Two-year factory warranty
Honeywell 3320G-4-N Barcode Scanner Overview
The Vuquest™: 3320g compact area-imaging scanner offers aggressive scanning of all 1D, PDF and 2D barcodes in a lightweight, durable and portable form factor. The scanner':s sleek and elegant design also blends seamlessly in retail environments, providing superior-performance scanning of all printed barcodes, and digital barcodes on any smart device.
TotalFreedom enables the loading and linking of multiple applications directly onto the scanner, eliminating the need for host system modi cations while offering expanded decoding and data formatting functionality.
A flexible licensing solution allows current scanning needs to be met while protecting the option to upgrade scanning capabilities in the future by simply purchasing a license for the appropriate feature.
Laser-free aiming provides an accurate scan indication, creating a customer-friendly operating environment while removing the risk of eye injury.
Easily scans barcodes directly from mobile device or computer screens, almost as if they were printed on paper.
The intelligent multi-interface design supports all popular interfaces in one device, replacing the time-consuming process of scanning programming barcodes with automatic interface detection.
Designed with the customer in mind, the unobtrusive illumination contained within the Vuquest 3320g scanner reduces the annoying after-effects commonly associated with the illumination used in imaging-based scanners.The TotalFreedom™: 2.0 second-generation development platform expands scanner functionality by allowing decoding and formatting plug-ins to be loaded directly onto the Vuquest 3320g scanner, enabling enterprises to rapidly support proprietary or newly developed symbologies. The ability to control the triggering of an external device such as a beeper, photo eye or illumination via external I/O capabilities allows the Vuquest 3320g scanner to enter new markets once reserved for expensive industrial products.With its small size, ergonomically friendly thumb-activated button and clearly visible indicator LEDs, the Vuquest 3320g scanner offers a dependable handheld or wearable scanning solution. The Vuquest 3320g scanner also offers universal mounting and robust presentation mode scan performance, making the device an ideal fixed-mount scanning solution for use in light industrial applications and kiosks.
What barcode types can the Honeywell 3320G scanner read?
The Honeywell Vuquest 3320g is a 2D area-imaging scanner that reads all 1D barcodes, PDF417, and 2D barcodes including QR codes. It features Adaptus Imaging Technology 6.0 for superior barcode scanning performance across a wide range of symbologies. For a complete list of all supported barcode formats, visit Honeywell's symbologies page.
Can the 3320G scanner read barcodes on mobile phone screens?
Yes, the Honeywell 3320g features mobile phone reading technology and can aggressively scan barcodes displayed on mobile device screens. This eliminates the need to purchase additional specialty hardware for mobile barcode capture, making it ideal for modern retail and logistics environments.
Is the Honeywell 3320G a hands-free scanner?
Yes, the Vuquest 3320g is available as a hands-free scanner option, making it suitable for high-volume scanning applications in retail and warehouse environments. Its compact, lightweight design allows for flexible mounting while maintaining the ability to scan all barcode types efficiently.
What interfaces does the 3320G scanner support?
The Honeywell Vuquest 3320g features intelligent multiple interface design that supports popular interfaces on a single device. However, please note that cables are sold separately, so you'll need to specify your required interface type when ordering. Contact us today to confirm the specific interface options available for your application.
What environments is the 3320G scanner designed for?
The Honeywell 3320g is designed for retail and general-purpose barcode scanning environments with its sleek, elegant design that blends seamlessly into modern retail settings. The scanner features unobtrusive illumination that reduces eye strain compared to traditional imaging scanners, and it delivers aggressive reading performance even on highly reflective surfaces like mobile phone screens.
Is the Honeywell 3320G still available, or has it been discontinued?
The Honeywell Vuquest 3320g has been discontinued by the manufacturer. However, we may have remaining inventory available from our stock. Contact us today at barcodesinc.com to inquire about availability or to discuss alternative 2D imaging scanner solutions that meet your current needs.
The Honeywell 3320G-4-N Barcode Scanner is also known as
HSM-3320G4N
or 3320G4N.
Full specifications (PDF)
