Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
Linear:
- ABC Codabar (American Blood Commission)
- BC412
- China Post
- Codabar
- Code 11
- Code 128
- Code 32 Pharmaceutical (PARAF)
- Code 39
- Code 93 and 93i
- EAN-13 (including Bookland EAN)
- EAN-13 with Add-On
- EAN-13 with Extended Coupon Code
- EAN-8
- EAN-8 with Add-On
- GS1 Databar Expanded
- GS1 Databar Limited
- GS1 DataBar Omnidirectional
- GS1 Databar Truncated
- GS1-128
- Interleaved 2 of 5
- ISBT 128
- ITF-14
- Label Code
- Matrix 2 of 5
- MSI-Plessey
- UK Plessey Code
- PosiCode
- Straight 2 of 5 IATA
- Straight 2 of 5 Industrial
- Telepen
- Trioptic Code
- UPC-A
- UPC-A with Add-On
- UPC-A with Extended Coupon Code
- UPC-E
- UPC-E with Add-On
- UPC-E1 (obsolete)
Stacked:
- Codablock F
- Code 16K
- Code 49
- GS1 Composite
- GS1 Databar Expanded Stacked
- GS1 Databar Stacked
- GS1 Databar Stacked Omnidirectional
- MicroPDF417
- PDF417
- TCIF Linked Code 39 (TLC39)
Matrix:
- Aztec Code
- Aztec Mesas
- Chinese Sensible Code (Han Xin Code)
- Data Matrix
- Grid Matrix Code
- MaxiCode
- QR Code and Micro QR Code
Postal:
- Australian Post
- British Post
- Canadian Post
- ID-tag (UPU 4-State)
- Intelligent Mail Barcode
- Japanese Post
- Netherlands (KIX) Post
- Korea Post
- Planet Code
- Postnet
OCR:
- OCR MICR (E 13 B)
- OCR SEMI Font
- OCR US Money Font
- OCR-A
- OCR-B
Light Source:
LED
Image Sensor Type:
Imager
Maximum Scan Resolution:
5 mil
Depth of Field:
- 1.9" - 3.8"@5mil
- 1.6" - 6.2"@13mil - UPC
- 1.6" - 4.5"@6.6mil - PDF
- 2.4" - 3.5"@6.7mil - DM
- 2.3" - 3.4"@6.7mil - QR
Scan Pattern:
Omni-directional
