Honeywell Granit Ultra 2100iXR – Barcode Scanner – Corded – 1D, 2D – FlexRange

Part Number: 2100IXR-3SERN
3-year Premium Plus ($54.70)
No, stay at premium support package
$695.93
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Handheld
Interface Options
USB
Scanner Capability
1D, 2D

Product Description:

  Barcode Scanner, Honeywell Granit Ultra 2100iXR, Granit Ultra RS232 Kit: Tethered, Rugged, 1D/2D, FlexRange, Vibrator, Red Scanner (2100IXR-3SER), RS232 Cable (CBL-020-300-C00), NA

Honeywell Granit Ultra 2100iXR Barcode Scanner Model Overview

The Honeywell Granit™ Ultra 2100iXR is an ultra-rugged area-imaging expanded range scanner designed to enhance productivity in warehouses, distribution centers, and manufacturing environments. With rapid scanning capabilities that outperform standard models, it efficiently reads damaged or low-quality barcodes, preventing costly delays in workflow. The ergonomic design and extended scanning range make it comfortable for users while facilitating efficient data capture from distances of up to 33 feet, effectively improving operational ergonomics.


Key Features

  • Ultra Durability: Withstands 10-foot drops and 7,500 tumbles, ensuring longevity even in harsh environments.
  • Fast Scanning: Achieves an average of 45% faster scanning speed on both 1D and 2D barcodes.
  • Easy to Use: Immediate operation out of the box and comfortable design for all users.
  • High Performance: Decodes barcodes from close range to 33 feet for improved productivity.

Specifications

  • Physical Characteristics:
    • Dimensions: 194.8mm x 75.8mm x 139.5mm
    • Weight: 330g (11.64 oz)
  • Electrical:
    • Input Voltage: 4.4 to 5.5 VDC
    • Operating Power (USB): 2.15W
  • Environmental:
    • Operating Temperature: -30°C to 50°C
    • Sealing: IP65 and IP68
  • Performance:
    • Scan Angle: Horizontal 42°, Vertical 36°
    • Decode Capabilities: 1D, 2D, PDF, and more
Honeywell 2100IXR-3SERN Barcode Scanner Overview

Honeywell Granit Ultra scanners expand capabilities and define the next generation of ultra-rugged scanning.

ULTRA SCAN PERFORMANCE

For a scanner to optimize productivity, it should read and transmit common barcodes nearly as fast as the user can pull the trigger. Granit Ultra is engineered to do just that. Damaged or low quality printed barcodes can cause scanners' pace to decrease, or even force cumbersome (and error-prone) manual data entry. To maximize throughput, scanners must successfully compensate for poor code quality before scan delays put pressure on production

Granit Ultra integrates high speed processing, AI algorithms, and decoding enhancements to result in an average 45% scanning speed increase vs. Granit XP, enabling improved productivity. SR models are ready for action, reading barcodes from contact to arm's length.

ULTRA DURABILITY

In modern warehouse, distribution center, and manufacturing environments, any scanner must be durable enough to survive harsh operating conditions and powerful enough to capture and transmit barcode data without slowing workflows. Under exactly that kind of rough treatment, Honeywell Granit Ultra is ready to deliver. 10' drops from fork trucks, docks, and picking trucks, 7,500 tumbles from 3'/1m (typical working height), and wide operating temperatures from deep freezers to the heat of summer are no problem.

But great specs alone are meaningless if there are other weak links in the chain. For instance, customers often cite scratched and broken scan windows as a frequent failure point in competitive scanners. Honeywell Granit Ultra's small, deeply recessed, scratch- and impact-resistant scan window is designed to address this, helping ensure that the electronics and optics remain IP65/68 protected. Scanner cables are another commonly reported failure point for other brands. Honeywell's rigorous specifications on scanner cables (including 500K cycle flex, weighted pull, and even deep freezer specific versions tested to 300K flexes at a frigid -30C/-22F) ensure that each link in the data chain offers premium reliability.

ULTRA EASE OF USE

Ready to operate right out of the box for many applications, Granit offers easy custom configuration in the time it takes to scan a barcode. Comfortable ergonomic design compliments the human hand and is readily compatible with the range of users. Crisply focused illumination intuitively defines the field of view, and a sharp aimer both defines the focal point and can be used for precise targeting in applications where many barcodes are located close together. And for workflows better expedited by reading many barcodes at once, Granit can read multiple codes in the field of view, organizing and outputting the data in a predefined order using Honeywell's Data Format Editor.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
  • Reads standard 1D, PDF, 2D, Postal, Digimarc, DOT Code, and OCR symbologies
Light Source:
Laser
Image Sensor Type:
Imager
Scan Pattern:
Area
Scanner Range:
FlexRange
Scanning Distance:
35.59 ft
Features:
  • Vibration
  • Beep
  • Notification LED
  • Ergonomic Design
Field of View (Horizontal):
42°
Field of View (Vertical):
36°
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Motion Tolerance:
157 in/s
Maximum Ambient Light:
100000 lux
Drop Specification:
  • 3m (10 ft): MIL-STD-810G, 25C (77°F), 55% RH
  • 2.5m (8 ft): 20 drops from -30°C to 50°C (-22°F to 122°F), uncontrolled RH
  • 2m (6.5 ft): 50 drops from -30°C to 50°C (-22°F to 122°F), uncontrolled RH
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
100 mil
Minimum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (DataMatrix):
100 mil
Minimum Element Resolution (PDF417):
6.7 mil
Image Sensor Resolution:
1280 x 1080
Illumination Type:
LED
Illumination Color:
Green
Air Electrostatic Discharge (+/-):
20kV
Contact Electrostatic Discharge (+/-):
8kV
Interfaces/Ports
Host Interface:
USB
Power Description
Maximum Operating Power Consumption:
2.75 W
Standby Current:
175 mA
Environmental Conditions
Operating Temperature:
-22°F (-30°C) to 122°F (50°C)
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing):
95%
Physical Characteristics
Form Factor:
Handheld
Rugged:
Yes
Durability:
  • Impact Resistant
  • Scratch Resistant
  • Drop Resistant
Height:
5.5"
Width:
3"
Length:
7.7"
Weight (Approximate):
11.64 oz
Miscellaneous
Ingress Protection (IP) Rating:
  • IP65
  • IP68
Application/Usage:
  • Warehouse
  • Distribution
  • Manufacturing
  • Picking
  • Packing
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211701

Frequently Asked Questions

The Honeywell Granit Ultra 2100iXR offers extended range scanning from near contact up to 33 feet, making it ideal for versatile warehouse and distribution center applications where you need flexibility in scanning distance. This extended range capability allows operators to scan barcodes on high shelves, pallets, and distant locations without repositioning.

The 2100iXR is built for extreme durability with IP65/IP68 sealing, impact-resistant design, and the ability to withstand 10-foot drops and 7,500 tumbles. It also operates reliably in harsh temperature ranges from -22°F to 122°F, making it suitable for freezer storage, outdoor loading docks, and other challenging warehouse conditions.

The Honeywell Granit Ultra 2100iXR reads 1D, 2D, Postal, OCR, and Digimarc barcodes with ease, providing comprehensive compatibility across most inventory and logistics systems. This multi-format capability ensures seamless integration with your existing warehouse management infrastructure.

The 2100iXR delivers 45% faster scanning speeds compared to previous Granit models, even when scanning damaged or low-quality barcodes. This performance improvement translates to increased productivity and throughput in high-volume warehouse and distribution operations.

The 2100iXR-3SERN is a tethered RS232 kit that includes an RS232 cable (CBL-020-300-C00) for direct connection to your host systems. The scanner supports multiple host interfaces including USB, Keyboard Wedge, and RS-232 TTL, with cables available to convert for +/-12V True use if needed.

Yes, the 2100iXR features advanced AI algorithms and high-speed processing specifically designed to read damaged or low-quality barcodes reliably. This capability is particularly valuable in warehouse environments where barcodes may become worn, faded, or partially obscured during handling and storage.

The Honeywell 2100IXR-3SERN Barcode Scanner is also known as HSM-2100IXR3SERN or 2100IXR3SERN.
