Full specifications (PDF)
Connectivity Technology:
Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
Reads standard 1D, PDF, 2D, Postal, Digimarc, DOT Code and OCR symbologies
Image Sensor Type:
Imager
Scan Pattern:
Area
Scanner Range:
Standard Range
Scanning Distance:
33"
Features:
- Beep
- Vibration
- Notification LED
Field of View (Horizontal):
40°
Field of View (Vertical):
30°
Reading Angle (Skew):
65°
Reading Angle (Pitch):
45°
Reading Angle (Roll):
-360°
Motion Tolerance:
177 in/s
Maximum Ambient Light:
100000 lux
Drop Specification:
- 2 m (6.5 ft): 50 drops from -30°C to 50°C (-22°F to 122°F), uncontrolled RH
- 2.4 m (8 ft): 20 drops at 25°C (77°F), 55% RH
- 3 m (10 ft): MIL-STD-810G, 25°C (77°F), 55% RH
Minimum Print Contrast:
20%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
20 mil
Minimum Element Resolution (DataMatrix):
6 mil
Maximum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
6.7 mil
Image Sensor Resolution:
1280 x 800
Air Electrostatic Discharge (+/-):
20kV
Contact Electrostatic Discharge (+/-):
8kV
