Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
- Reads standard 1D, PDF, 2D, Postal Digimarc, DOT Code, and OCR symbologies
Light Source:
LED
Image Sensor Type:
Imager
Scanner Range:
Standard Range
Scanning Distance:
43.90"
Features:
- Beep
- Notification LED
Field of View (Horizontal):
42°
Field of View (Vertical):
36°
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Motion Tolerance:
157.48 in/s
Maximum Ambient Light:
100000 lux
Drop Specification:
1.8 m (6 ft) to concrete across operating temp range
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
3 mil
Maximum Element Resolution (Code 39):
20 mil
Minimum Element Resolution (DataMatrix):
5 mil
Maximum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
5 mil
Maximum Element Resolution (PDF417):
6.7 mil
Image Sensor Resolution:
1280 x 1080
Illumination Type:
LED
Illumination Color:
White
Air Electrostatic Discharge (+/-):
15kV
Contact Electrostatic Discharge (+/-):
8kV
