Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
Linear:
- China Post
- Codabar (NW7)
- Code 11
- Code 128
- Code 32
- Code 39
- Code 93
- Code 2 of 5
- EAN
- Interleaved 2 of 5
- Matrix 2 of 5
- MSI
- GS1 DataBar (formerly RSS)
- Telepen
- Trioptic Code
- UPC
Stacked:
- Codablock F
- GS1 Composite (formerly EAN/UCC)
- MicroPDF417
- PDF417
Matrix:
- Aztec
- Chinese Sensible Code (Han Xin Code)
- Data Matrix
- MaxiCode
- QR Code
- Micro QR Code
Postal:
- Intelligent Mail Barcode (formerly 4-state customer barcode)
- Australian Post
- British Post
- Canadian Post
- ID-tag (UPU 4-state)
- Japanese Post
- Netherlands (KIX) Post
- Planet Code
- Postnet
OCR:
- OCR-A
- OCR-B
- OCR MICR (E 13 B)
Image Sensor Type:
Imager
Maximum Scan Resolution:
5 mil
Depth of Field:
- 0" - 3.6"@5mil - Code 39
- 0.4" - 5.9"@13mil - UPC
- 0.4" - 8.4"@20mil - Code 39
- 0" - 3.8"@6.7mil - PDF417
- 0" - 4.2"@10mil - Data Matrix
- 0.4" - 6.8"@20mil - QR
Scan Pattern:
Linear
