HID 6005BKB00 Access Control Reader

Part Number: 6005BKB00
Model: 6005
$121.99
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Identification Method
Proximity
Operating Range
7.60"
Application/Usage
DoorIndoorOutdoor
Ingress Protection (IP) Rating
IP55

Product Description:

  125 kHz Mini Mullion Proximity Reader (Pigtail and Config 00) - Color: Black

HID 6005 Access Control Reader Model Overview

The HID ProxPoint® Plus Reader combines affordable pricing with reliability and security in access control. With a sleek, inconspicuous design, this proximity card reader offers seamless integration for both indoor and outdoor settings. Its robust construction ensures durability, while the secure potted electronics deliver high performance. Compatible with various formats and access control systems, the reader features customizable audiovisual indicators, making it ideal for diverse site requirements.


Key Features
  • Multiple Configuration Options: Extensive beeper and multicolor LED settings for customization based on site needs.
  • Built for Durability: Rugged, weatherized polycarbonate enclosure ensures reliability in harsh environments.
  • Wide Compatibility: Compatible with standard access control systems, reading HID cards with formats up to 85 bits.
  • Flexible Mounting: Can be mounted directly onto metal surfaces without affecting read range performance.
  • Lifetime Warranty: Comprehensive warranty against defects in materials and workmanship.

Specifications
  • Mounting: Directly onto metal surfaces
  • Power Supply: 5-16 VDC
  • Current Requirements:
    • Average: 30 mA
    • Peak: 75 mA
  • Operating Temperature: -22° to 150° F (-30° to 65° C)
  • Operating Humidity: 0-95% relative humidity, non-condensing
  • Weight: 2.7 oz. (75 gm)
  • Dimensions: 3.135" x 1.720" x 0.660" (7.96 x 4.37 x 1.68 cm)
  • Environmental Rating: IP55
  • Cable Distance: 500 feet (150 m) for Wiegand or Clock-and-Data interfaces
HID 6005BKB00 Access Control Reader Overview

HID's ProxPoint® Plus reader combines multiple configuration options with an attractive, inconspicuous design and economical price. Its secure potted electronics are ideal for both indoor and outdoor applications.

  • Small sized, low cost reader features a beeper and multicolor LED which can be host and/or locally controlled.
  • Potted reader suitable for indoor or outdoor use.
  • 18" (45 cm) wire pigtail standard; consult factory for 9' (2.7 m) pigtail available by special order.
  • Classic Series covers available in black, gray, white or beige. Designer Series covers available in black or gray.
Technical Information
Identification Method:
Proximity
Operating Range:
7.60"
Application/Usage:
  • Door
  • Indoor
  • Outdoor
Ingress Protection (IP) Rating:
IP55
Interfaces/Ports
Wiegand:
Yes
Power Description
Input Voltage:
16 V DC
Physical Characteristics
Product Color:
Classic Black
Height:
0.7"
Width:
1.7"
Depth:
3.1"
Weight (Approximate):
2.65 oz
Miscellaneous
Package Contents:
  • 125 kHz Mini Mullion Proximity Reader
  • Multilingual Installation Manual
Compatibility:
  • ProxCard II Card
  • ISOProx II Card
  • DuoProx II Card
  • Smart ISOProx/DuoProx II Cards
  • Proximity & MIFARE Card
  • ProxCard Plus Card
  • ProxKey II key Fob
  • MicroProx Tag
Environmentally Friendly:
Yes
Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0133588234823, 0639399220456, 0999562170330, 5311090267866
UPC: 133588234823, 639399220456, 999562170330
EAN: 0133588234823, 0639399220456, 0999562170330, 5311090267866
UNSPSC: 46171600
