HID 5455BWN00 Access Control Card Reader

HID ProxPro II 5455 Wall Switch Proximity Reader - ProxPro II Reader - 8" Operating Range - Wiegand - White
  • Security - Recognizes card formats up to 84 bits, with over 1.93x1025 unique codes.
  • Installation - Easy, streamlined installation procedure is consistent with HID's ThinLine® II, MiniProx® and ProxPoint® Plus readers. Included installation manual features instructions in English, French, German, Spanish, Portuguese, Chinese and Japanese.
  • Audiovisual Indication - When a proximity card is presented to the reader, the red LED flashes green and the beeper sounds. The multicolor LED and beeper can also be controlled individually by the host system.
  • Diagnostics - On reader power-up, an internal self-test routine checks and verifies the setup configuration, determines the internal or external control of the LED and beeper, and initializes reader operation. An additional external loop-back test allows for the reader outputs and inputs to be verified without the use of additional test equipment.
  • Indoor/outdoor Design - Sealed in a rugged, weatherized polycarbonate enclosure designed to withstand harsh environments, providing reliable performance and a high degree of vandal resistance. Two-piece reader design allows for easy installation.
  • Easily Interfaced - Wiegand output model interfaces with all existing Wiegand protocol access control systems. Clock-and-Data (magnetic stripe) model interfaces with most systems that accept magnetic stripe readers.
  • Options - Termination: 18" (45 cm) pigtail standard, 9' (2.7m) available by special order. Mounting: glass mounting kit available separately. LED and beeper operation.
Read More
$180.76
Temporarily out of stock; available to order

Full specifications (PDF)

Ideal for medium-range applications
HID's 5455 proximity reader for access control combines performance, reliability, and ease of installation into a two-piece, weatherproof potted enclosure. International users will appreciate the multilingual installation manual, lower voltage requirement and flexible mounting options.
HID 5455BWN00 Overview

NEW GENERATION PROXIMITY CARD READER

HID's ProxPro® II proximity reader for access control combines performance, reliability, and ease of installation into a two-piece, weatherproof potted enclosure. International users will appreciate the multilingual installation manual, lower voltage requirement and flexible mounting options.

Protect Your Product

Full specifications (PDF)

Technical Information
Maximum Operating Range:
8"
Interfaces/Ports
Host Interface:
Wiegand
Physical Characteristics
Color:
White
Height:
5"
Width:
5"
Depth:
1"
Weight (Approximate):
13.65 oz
Miscellaneous
Package Contents:
  • ProxPro II Reader
  • Installation Manual
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
Lifetime
Item Numbers
UNSPSC: 43201815


The HID 5455BWN00 is also known as HID-5455BWN00 .
