Hanwha Vision PNM-9085RQZ1 Security Camera

Part Number: PNM-9085RQZ1
Model: Parts
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$3,653.85
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
HD Recording
Yes
Night Vision
Yes
Night Vision Distance
98.43 ft
Night Vision Type
Infrared

Product Description:

  Security Cameras, Hanwha Techwin America PNM-9085RQZ1, Wisenet, 20 Megapixel Network Camera, Color, Dome, TAA Compliant, 98.43 ft Infrared Night Vision, H.265, H.264, MJPEG, H.265H, H.265M, H.265B, H.264B, H.264M, H.264H, 2560 x 1920, 4.13 mm- 9.40 mm Varifocal Lens, 2.3x Optical, CMOS, Hanging Mount, IK10, IP66
Explore all Hanwha Vision Parts Security Cameras
Add to Quote
Hanwha Vision PNM-9085RQZ1 Security Camera
Hanwha Vision PNM-9085RQZ1 Security Camera
Hanwha Vision PNM-9085RQZ1 Security Camera Hanwha Vision PNM-9085RQZ1 Security Camera

Hanwha Vision Parts Security Camera Model Overview

Parts and products from Hanwha Vision.
Technical Information
HD Recording:
Yes
Night Vision:
Yes
Night Vision Distance:
98.43 ft
Night Vision Type:
Infrared
Display & Graphics
Image Sensor Type:
CMOS
Color Supported:
Color
Field of View:
H: 87.58°(Wide)~37.34°(Tele) / V: 64.58°(Wide)~28.04°(Tele) / D: 112.46°(Wide)~46.85°(Tele)
Effective Camera Resolution:
20 Megapixel
Number of Sensors:
4
Video
Video Formats:
  • H.265
  • H.264
  • MJPEG
  • H.265H
  • H.265M
  • H.265B
  • H.264B
  • H.264M
  • H.264H
Maximum Video Resolution:
2560 x 1920
Maximum Frame Rate:
30 fps
Lens
Lens Type:
Varifocal
Minimum Focal Length:
4.13 mm
Maximum Focal Length:
9.40 mm
Lens Included:
Yes
Minimum Aperture:
f/2.67
Maximum Aperture:
f/1.9
Optical Zoom:
2.3x
Exposure
Shortest Shutter Speed:
1/12000 Second
Longest Shutter Speed:
2 Second
Network & Communication
Connectivity Technology:
Wired
Remote Management:
Yes
Storage
Storage Type:
Memory Card
Interfaces/Ports
Network (RJ-45):
Yes
Power Description
Power Source Type:
  • DC
  • PoE
Physical Characteristics
Mount Type:
Hanging Mount
Form Factor:
Dome
Product Color:
White
Diameter:
12.4"
Weight (Approximate):
11.46 lb
Environmental Conditions
Minimum Operating Temperature:
-40°F (-40°C)
Maximum Operating Temperature:
131°F (55°C)
Operating Humidity:
90%
Miscellaneous
Features:
  • SD Card Local Storage
  • Day/Night
  • Automatic White Balance
  • Highlight Compensation (HLC)
  • Back Light Compensation (BLC)
  • Digital Wide Dynamic Range (D-WDR)
  • Wide Dynamic Range
  • Gain Control
  • Password Protection
  • Alarm Triggering
  • Digital Image Stabilization
  • Defog
Impact Protection Rating:
IK10
Ingress Protection Rating:
IP66
TAA Compliant:
Yes
Item Numbers
GTIN: 8801089216830, 8801089216946
EAN: 8801089216830, 8801089216946
UNSPSC: 46171610
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Hanwha Vision PNM-9085RQZ1 Security Camera is also known as HAN-PNM9085RQZ1
