Hand Held ImageTeam 5620 – Barcode Scanner – 1D

Part Number: 5620SR0C0B-0GA0
Model: ImageTeam 5620
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Scanner Capability
1D

Product Description:

  PS/2 interface. Includes Imager, Base, US Power Supply, System Manual and Battery Pack. (Formerly listed as (Part# 5620SR0C0-0GA0). PS/2 Cable not included, see (Part# 42206132-02).
Explore all Hand Held ImageTeam 5620 Barcode Scanners
Add to Quote
Hand Held 5620SR0C0B-0GA0 Barcode Scanner
Hand Held 5620SR0C0B-0GA0 Barcode Scanner
Hand Held 5620SR0C0B-0GA0 Barcode Scanner
Hand Held 5620SR0C0B-0GA0 Barcode Scanner Hand Held 5620SR0C0B-0GA0 Barcode Scanner Hand Held 5620SR0C0B-0GA0 Barcode Scanner
Full specifications (PDF)

Hand Held ImageTeam 5620 Barcode Scanner Model Overview

The superior ergonomics of the Hand-Held ImageTeam 5620 delivers comfortable operation in traditional barcode reading mode or hands-free operation. Bluetooth technology enables wireless communication, and its unique design takes up less space at the POS area. Powered by Hand-Held' exclusive Adaptus Imaging Technology, the new ImageTeam 5620 Cordless Imager combines great reading performance, durability, and mobility all in one package.
Hand Held 5620SR0C0B-0GA0 Barcode Scanner Overview

IMAGETEAM 5620 Bar Code Reader combines exclusive Adaptus Imaging Technology with Bluetooth wireless connectivity to provide class-leading performance and durability for retail and commercial cordless bar code reading.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Wireless
Scanning Capability:
1D
Barcode Symbology Supported:
  • China Post
  • Codabar
  • Codablock F
  • Code 11
  • Code 2 of 5
  • Code 16K
  • Code 39
  • Code 32 Pharmaceutical (PARAF)
  • Code 128
  • Code 49
  • EAN/JAN
  • IATA 2 of 5
  • Interleaved 2 of 5
  • Korea Post
  • Matrix 2 of 5
  • Coupon Code
  • MSI
  • Plessey Code
  • PosiCode
  • RSS-14
  • Telepen
  • Trioptic
  • UPC-A
  • UPC-E
  • GTIN Compliant
Light Source:
LED
Image Sensor Type:
Linear
Scan Rate:
270 scan/s
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 1" - 24"
Scanning Distance:
32.81 ft
Network & Communication
Bluetooth:
Yes
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
3.6 V DC
Power Source:
Battery
Power Supply Included:
Yes
Battery Information
Battery Chemistry:
Lithium Ion (Li-Ion)
Physical Characteristics
Weight (Approximate):
9.20 oz
Miscellaneous
Package Contents:
  • IMAGETEAM 5620 Bar Code Reader
  • Base Station
  • Battery Pack
  • US Power Supply & Power Cord
  • Manual
Additional Information:

Supported Interfaces:

  • Keyboard Wedge
  • USB
  • TTL level RS-232
  • TTL level Serial Wedge
  • Wand Emulation
  • IBM 46XX

    • Platform Supported:
    PC
    Warranty
    Limited Warranty:
    3 Year
    Item Numbers
    UNSPSC: 43211701
    Get help from a Barcoding Expert!

    What type of Barcode are you scanning?

    The Hand Held 5620SR0C0B-0GA0 Barcode Scanner is also known as HHP-5620SR0C0B0GA0 or 5620SR0C0B0GA0.
