Hand Held ImageTeam 3800 – Barcode Scanner – 1D

Part Number: 3800LX-12BLKE
Model: ImageTeam 3800
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Scanner Capability
1D
Scanner Type
Imager

Product Description:

  Extended long range linear imager, Commercial interface, RoHS, No User Guide, Color: Black
Explore all Hand Held ImageTeam 3800 Barcode Scanners
Add to Quote
Hand Held 3800LX-12BLKE Barcode Scanner
Hand Held 3800LX-12BLKE Barcode Scanner
Hand Held 3800LX-12BLKE Barcode Scanner Hand Held 3800LX-12BLKE Barcode Scanner
Full specifications (PDF)

Hand Held ImageTeam 3800 Barcode Scanner Model Overview

This durable model is excellent in handheld scanning applications, such as point of sale where hand scanning is required for large bulky items, shipping and warehousing or anywhere where low to medium density barcodes are being read 2 to 3 feet away. The ImageTeam 3800 can be used indoors or outside in bright sunlight.
Hand Held 3800LX-12BLKE Barcode Scanner Overview

The IMAGETEAM 3800LX is a longer range, high performance, hand held Bar Code Reader. The IT3800LX uses linear imaging technology to match the reading distance of standard range lasers with a bright, sharp aiming line and high resolution imaging to deliver exceptional reading

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • Codabar
  • Code 3 of 9 including PARAF
  • Interleaved 2 of 5
  • Code 2 of 5
  • Code 128
  • UPC
  • EAN/JAN
  • China Postal Code
  • RSS
Light Source:
LED
Image Sensor Type:
Linear
Scan Rate:
270 scan/s
Maximum Scan Resolution:
6.50 mil
Depth of Field:
  • 1.5" - 14"@100% UPC
Scan Pattern:
Linear
Cable Type Included:
USB
Interfaces/Ports
Host Interface:
Keyboard Wedge
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Form Factor:
Handheld
Color:
Black
Height:
6"
Width:
3.1"
Depth:
5.3"
Weight (Approximate):
6.30 oz
Miscellaneous
Package Contents:
  • IMAGETEAM 3800LX Bar Code Reader
  • USB Cable
Additional Information:

Supported Interfaces:

  • Keyboard Wedge
  • TTL RS-232
  • Wand Emulation
  • HHLC

USB Cable separate

Certifications & Standards:
  • FCC Class B
  • CE EMC Class B
  • CE Low Voltage Directive
  • IEC60825-1 LED Safety: Class 1
  • UL
  • cUL listed
  • TUV
  • RoHS
Warranty
Limited Warranty:
5 Year
Item Numbers
UNSPSC: 43211701
