FEIG 3249.000.00 RFID Antenna

The HF Loop Antenna ID ANT310/310 is an advanced solution for a variety of applications, including libraries, document tracking, and logistics. With a maximum transmission power of 8 W and a robust IP65 protection class, it is built for both indoor and outdoor usage. The antenna's manual alignment electronics facilitate optimal adjustment to different environments, ensuring reliable performance with various HF readers by FEIG ELECTRONIC. Achieve impressive read ranges of up to 70 cm, making it an ideal choice for efficient data acquisition and access control.

Key Features:

• Transmission Power: Up to 8 W
• Protection Class: IP65 for durable usability
• Versatile Applications: Suitable for libraries, logistics, and access control
• Manual Alignment: Electronics for optimal performance adjustments
• Read Range: Up to 70 cm with selected readers

Specifications:

• Dimensions: 318 mm x 338 mm x 30 mm
• Weight: Approx. 700 g
• Housing Material: Plastic ASA, Color: White
• Temperature Range: -25 °C to +55 °C (operation), -25 °C to +60 °C (storage)
• Relative Humidity: 5% to 95% (non-condensing)
• Operating Frequency: 13.56 MHz
• Antenna Connection: 1 x SMA plug (50 N) with RG58 cable (3.6 m)
• Standard Conformity: EN 300 330, FCC Part 15
