FEIG 2396.000.00 RFID Antenna

The ID ANT340/240 HF Pad Antenna is expertly crafted for seamless contactless data exchange with HF transponders. With a sleek and elegant design, this flat external antenna is perfect for desktop applications in offices and libraries, optimally facilitating the tracking and managing of files and documents. With an impressive read range of up to 30 cm, this antenna ensures efficient monitoring and capturing of loaned items, further enhancing productivity in any environment.

Key Features

• Read Range: Up to 30 cm
• Elegant Design: Sleek and flat for aesthetic integration in any setting
• Versatile Use: Suitable for various applications in offices and libraries
• Easy Operation: Connects directly with a reader for instant use
• Options Available: Offered as both an antenna module and in a plastic housing

Specifications

• Dimensions: 337 mm x 237 mm x 8 mm
• Weight: Approx. 530 g
• Housing: Plastic (ABS)
• Color: Grey-white
• Protection Class: IP40
• Temperature Range:
  • Operation: 0°C to +55°C
  • Storage: -25°C to +85°C
• Relative Air Humidity: 5% to 95% (non-condensing)
• Operating Frequency: 13.56 MHz
• Max. Transmitting Power: 1.2 W
• Antenna Connection: 1 x SMA plug (50 Ω)
• Antenna Connection Cable: RG58 coaxial cable with SMA plug (50 Ω); length 230 cm
• Standard Conformity: EN 301 489, EN 62368-1, EN 50364
