FEIG 1524.005.01 RFID Mobile Reader

The FEIG HF Handheld Reader (ID PRH102-B / PRH101-USB) is designed for efficient contactless data exchange with ISO 15693 transponders, ideal for applications in retail, logistics, and industry. With a read range of up to 20 cm and a powerful anti-collision function, this reader can identify up to 30 transponders simultaneously. Its flexible interface options (USB and Bluetooth) ensure seamless integration into existing systems, while its lightweight design and robust construction make it perfect for handheld use.
Key Features:

• Variable interfaces: USB, Bluetooth
• Anti-collision function: Read up to 30 transponders at once
• Dual operation modes: FEIG ISO Host Mode & Scan Mode
• Integrated design: Compact and portable for easy handling
• Multi-tag reading capability: Compatible with ISO 15693 and ISO 18000-3 transponders

Specifications:

• Dimensions: 230 mm x 100 mm x 80 mm
• Weight: 320 g (without batteries)
• Housing: Plastic ABS
• Protection class: IP30
• Operating frequency: 13.56 MHz
• Read range: Up to 20 cm (PRH101-USB), up to 13 cm (PRH102-B)
• Battery: 4 Mignon cells (AA)
• Temperature range: 0°C to +50°C (operation), -20°C to +70°C (storage)
• Humidity: 5% to 95% (non-condensing)
