FEIG ID MRMU400 RFID Reader

Compact Power, Seamless RFID Integration.

FEIG ID MRMU400  -  The ID MRMU400 is a powerful, integration-ready UHF RFID reader module engineered for industrial automation. It delivers reliable performance with over 4 meters of read range, dual antenna support, and onboard edge computing—allowing real-time data processing right at the source. With robust security features and a compact, modular design, it’s the ideal solution for OEMs and system integrators looking to build smarter, faster, and more secure RFID-enabled systems.
Full specifications (PDF)

Price Match Guarantee

Found a better price? We'll match it within 30 days of your purchase.

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Starting at:
$1,186.15
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

FEIG ID MRMU400 RFID Reader
FEIG ID MRMU400 RFID Reader
FEIG ID MRMU400 RFID Reader FEIG ID MRMU400 RFID Reader

FEIG ID MRMU400 RFID Reader Options

  • FEIG 7027.000.10 RFID Reader

    FEIG 7027.000.10 RFID Reader
    RFID Reader, FEIG ID MRMU400, ID MRMU400-FCC UHF Mid Range Reader Module. Feig products require a $300 minimum order value. Orders below this amount will not be processed.
    $1,186.15
    Add to Quote
Full specifications (PDF)

FEIG ID MRMU400 RFID Reader Model Overview

The ID MRMU400 is a UHF Mid Range Reader Module designed by FEIG ELECTRONIC GmbH for industrial and machine integration applications.



Key Features

  • Output Power: Up to 1 Watt (adjustable in 100 mW steps)

  • Antenna Support: Connections for up to 2 antennas (MCX connectors with built-in multiplexer)

  • Read Range: Over 4 meters

  • Transponder Support: EPC Class1 Gen2, ISO 18000-63, ISO/IEC 29167 (e.g., NXP UCODE DNA)

  • Secure Operation: Secure key storage and support for encrypted communication

  • Edge Computing: Runs Linux OS on an ARM Cortex-A7 + M4 processor, enabling custom apps on the device

Interfaces & I/O

  • Inputs: 1 optocoupler input (max 24 V DC / 20 mA)

  • Outputs: 1 optocoupler + 1 relay output

  • Interfaces: RS485, Ethernet (IPv4/IPv6), USB OTG

Physical Design

  • Form Factor: Module without housing – ideal for integration into existing control boxes

  • Cooling: Aluminum mounting plate for heat dissipation

  • Protection: Comes with a plastic cover to prevent accidental contact or stress on electronics

Specifications

  • Dimensions: 185 x 135 x 35 mm

  • Weight: 535 g

  • Power Supply: 12–24 V DC ±10% or PoE+

  • Operating Temperature: -40 °C to +70 °C

  • Humidity Tolerance: 5% to 95% (non-condensing)

Software & Functionality

  • Reader modes: Host Mode, Buffered Read, Notification

  • Integrated diagnostics: RF monitoring, antenna SWR, overheating protection

  • Software features: EPCglobal™ LLRP, anti-collision, RSSI, phase angle, config cloning, web interface

Certifications

  • Radio: EN 302 208 (EU), FCC Part 15 (USA), IC RSS-247 (Canada)

  • EMC & Safety: EN 301 489, EN 62368-1, EN 50364

  • Cybersecurity: EN 18031-1
