FEIG ID LR5400 RFID Reader

Unmatched Range, Speed, and Reliability for Every RFID Challenge.

FEIG ID LR5400  -  The ID LR5400 is a rugged, high-frequency RFID reader that delivers unmatched range, speed, and flexibility. With up to 8W RF power, built-in Linux, and support for multiple antennas and protocols, it’s engineered for seamless integration into complex environments—from industrial automation to smart logistics.
Full specifications (PDF)

Price Match Guarantee

Found a better price? We'll match it within 60 days of your purchase.

Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Starting at:
$2,223.91
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

FEIG ID LR5400 RFID Reader
FEIG ID LR5400 RFID Reader
FEIG ID LR5400 RFID Reader FEIG ID LR5400 RFID Reader

FEIG ID LR5400 RFID Reader Options

  • FEIG 6194.000.00 RFID Reader

    FEIG 6194.000.00 RFID Reader
    RFID Reader, FEIG ID LR5400, ID ISC.LR5400-A HF Long Range Reader. Feig products require a $300 minimum order value. Orders below this amount will not be processed.
    $2,223.91
    Add to Quote
Full specifications (PDF)

FEIG ID LR5400 RFID Reader Model Overview

The ID LR(M)5400 is a 13.56 MHz High-Frequency Long Range RFID Reader designed by FEIG ELECTRONIC GmbH, tailored for industrial and commercial applications such as libraries, logistics, laundries, casinos, and other high-demand environments.



Key Features

  • High Performance & Sensitivity

    • Excellent reading/writing range (up to 2 meters)

    • Fast reading at high transponder densities

    • Homogeneous and stable tag detection

  • Integrated Multiplexer

    • 4 RF outputs

    • Supports additional external multiplexer for multi-antenna setups

    • RF power adjustable from 1 W to 8 W

  • Flexible Connectivity & Integration

    • IPv4/IPv6 support with DHCP, DNS, and NTP services

    • Interfaces: Ethernet (TCP/IP), USB Host/Slave, RS485

    • Embedded Linux OS with SDK for custom applications and protocol development

  • I/O Capabilities

    • 3 digital inputs (5–24 V)

    • 2 digital outputs (optocoupler)

    • 2 relay outputs (24 V, 1 A)

  • Diagnostics & Reliability

    • RSSI readout for tag localization

    • Built-in protections (antenna short-circuit, mismatching)

    • SWR analog measurements for diagnostics

    • 6 status LEDs

  • RFID Protocol Support

    • ISO 15693, ISO 18000-3-A, ISO 18000-3M3 (upgrade required), NXP I-Code 1

  • Environmental & Mechanical Specs

    • Operating temp: –20 °C to +55 °C

    • IP54-rated (for the ID LR5400 version with housing)

    • Dimensions:

      • LR5400: 320 × 180 × 110 mm (approx. 1.9 kg)

      • LRM5400 module: 160 × 120 × 46 mm (approx. 0.6 kg)

  • Certifications & Compliance

    • ETSI, FCC, IC, UL 62368, EN 62368-1 (radio, EMC, safety)
