Fargo 94654 ID Card Printer
Fargo Parts ID Card Printer Model Overview
Frequently Asked Questions
What encoding options does the Fargo 94654 support?
The Fargo 94654 supports multiple encoding technologies including 125 kHz (HID Prox) reader, 13.56 MHz contactless encoding (iCLASS, MIFARE, ISO 14443 A/B, ISO 15693), contact smart card encoding for all ISO7816 1/2/3/4 memory and microprocessor smart cards, and ISO magnetic stripe encoding with dual high- and low-coercivity on tracks 1, 2, and 3. This makes it ideal for comprehensive access control and credential programming applications.
Can the Fargo 94654 print on both sides of an ID card?
Yes, the Fargo 94654 is a dual-sided printer with a contact chip encoder and flattener included. The dual-sided configuration measures 9.8˝H x 18.7˝W x 9.2˝D and weighs 11 lbs, allowing you to produce professional ID cards with printing on both the front and back in a single pass.
What are the connectivity options for the Fargo 94654?
The Fargo 94654 features both USB 2.0 and Ethernet with internal print server connectivity, enabling centralized or remote ID card issuance from your network. Single wire Ethernet and USB 2.0 interfaces are available for inline printing and encoding, with single wire Ethernet encoding supported for iCLASS and contact smart card encoding.
What card sizes and thicknesses does the Fargo 94654 accept?
The Fargo 94654 accepts standard CR-80 cards (3.375˝L x 2.125˝W / 85.6mmL x 54mmW) and CR-79 adhesive back cards (3.313˝L x 2.063˝W / 84.1mmL x 52.4mmW). The printer supports card thickness from .009˝ to .040˝ (.229mm to 1.016mm) and works with PVC or polyester cards with polished PVC finish.
What is the warranty coverage for the Fargo 94654?
The Fargo 94654 includes a two-year warranty on the printer and a two-year warranty on the printhead with unlimited passes when using UltraCard™ cards. This comprehensive coverage ensures long-term reliability for your ID card issuance operations.
What operating conditions and power requirements does the Fargo 94654 need?
The Fargo 94654 operates at temperatures between 65° to 80° F (18° to 27° C) with humidity levels of 20–80% non-condensing. It requires 100-240 VAC supply voltage at 3.3 A and operates at both 50 Hz and 60 Hz frequencies, making it suitable for diverse facility environments. Contact us today to verify compatibility with your specific infrastructure requirements.
