Fargo 94653 ID Card Printer
Fargo Parts ID Card Printer Model Overview
Frequently Asked Questions
What encoding options does the Fargo 94653 HDP6600 support?
The Fargo 94653 supports multiple encoding technologies including 125 kHz HID Prox readers, 13.56 MHz contactless smart card encoding (iCLASS, MIFARE, ISO 14443 A/B, ISO 15693), contact smart card encoding for ISO7816 cards, and ISO magnetic stripe encoding with dual high- and low-coercivity support for Tracks 1, 2, and 3. This versatility makes it suitable for comprehensive credential issuance programs across access control, visitor management, and employee identification systems.
Is the Fargo 94653 a dual-sided card printer?
Yes, the Fargo 94653 is a dual-sided card printer with a magnetic stripe encoder and Flattener module included. The dual-sided configuration measures 9.8˝H x 18.7˝W x 9.2˝D and weighs 11 lbs, allowing you to print on both sides of ID cards in a single pass for enhanced security and information capacity.
What are the connectivity options for the Fargo 94653?
The Fargo 94653 features both USB 2.0 and Ethernet connectivity with an internal print server, enabling flexible deployment in centralized or remote ID card issuance environments. Single wire Ethernet and USB 2.0 interfaces are available for inline printing and encoding, with single wire Ethernet encoding supported for iCLASS and contact smart card applications.
What card sizes and thicknesses does the Fargo 94653 accept?
The Fargo 94653 accepts standard CR-80 cards (3.375˝L x 2.125˝W / 85.6mmL x 54mmW) and CR-79 adhesive back cards. The printer supports card thickness from .009˝ to .040˝ (9 mil to 40 mil / .229mm to 1.016mm), accommodating PVC or polyester cards with polished PVC finish for versatile credential applications.
What is the warranty coverage for the Fargo 94653?
The Fargo 94653 includes a two-year warranty on the printer and a two-year warranty on the printhead with unlimited pass usage when using UltraCard™ certified cards. This extended coverage protects your investment in high-volume ID card production environments.
What operating environment specifications should I consider for the Fargo 94653?
The Fargo 94653 operates in temperature ranges of 65° to 80° F (18° to 27° C) with humidity levels between 20–80% non-condensing. The printer requires 100-240 VAC power supply at 3.3 A and operates at both 50 Hz and 60 Hz frequencies, making it suitable for standard office and secure facility environments worldwide. Contact us today to discuss your specific deployment requirements.
