Fargo 94652 ID Card Printer
Fargo Parts ID Card Printer Model Overview
Frequently Asked Questions
What printing capabilities does the Fargo 94652 HDP6600 offer?
The Fargo 94652 is a double-sided retransfer ID card printer with a programmer module and Flattener, enabling high-quality dual-sided card production. It supports multiple encoding options including 125 kHz HID Prox readers, 13.56 MHz contactless smart card encoding (iCLASS, MIFARE, ISO 14443 A/B, ISO 15693), contact smart card encoding, and ISO magnetic stripe encoding across all three tracks. We offer this printer as a complete solution for secure credential issuance.
What software and diagnostic tools are included with the Fargo 94652?
The Fargo 94652 includes FARGO Workbench™ diagnostic utility with Color Assist™ spot-color matching to support printer maintenance and color optimization. The printer is interoperable with Asure ID® card personalization software for badge design, database management, and technology card encoding, as well as EasyLobby® Secure Visitor Management Solutions. Contact us today for software licensing and integration support.
What are the connectivity options for the Fargo 94652?
The Fargo 94652 features built-in Ethernet and USB 2.0 connectivity with an internal print server, enabling centralized or remote ID card issuance. Single wire Ethernet and USB 2.0 interface options are available for inline printing and encoding, with single wire Ethernet encoding available for iCLASS®, MIFARE®, and contact smart card encoding. Visit barcodesinc.com for configuration details.
What are the operating environment specifications for the Fargo 94652?
The Fargo 94652 operates in temperatures ranging from 65° to 80° F (18° to 27° C) with humidity levels between 20–80% non-condensing. It requires 100-240 VAC power supply at 3.3 A and supports both 50 Hz and 60 Hz frequencies. The printer carries UL 60950-1, CSA C22.2, and CE safety certifications with FCC Class A EMC compliance.
What warranty coverage is provided with the Fargo 94652?
The Fargo 94652 includes a two-year warranty on the printer and a two-year warranty on the printhead with unlimited pass coverage when using UltraCard™ media. This comprehensive coverage ensures reliable operation and support for your card issuance operations. Contact us today for warranty registration and support options.
What are the physical dimensions and weight of the Fargo 94652 dual-sided printer?
The Fargo 94652 dual-sided printer measures 9.8" H x 18.7" W x 9.2" D (249 mm H x 475 mm W x 234 mm D) and weighs 11 lbs (5 kg). When configured with the lamination module, the combined unit measures 18.9" H x 18.7" W x 9.2" D and weighs 20 lbs (9.1 kg). Available from us with flexible configuration options to match your workspace requirements.
