Fargo 88509 ID Card Printer
Fargo Parts ID Card Printer Model Overview
Frequently Asked Questions
What encoding options does the Fargo 88509 ID Card Printer support?
The Fargo 88509 supports multiple encoding technologies including 125kHz HID PROX reader, 13.56 MHz contactless encoding for iCLASS, MIFARE, ISO 14443 A/B, and ISO 15693 standards, contact smart card encoding for ISO7816 cards, and ISO magnetic stripe encoding with dual high- and low-coercivity support for tracks 1, 2, and 3. This versatility makes it suitable for access control credentials and multi-technology card programs.
What connectivity options are available on the Fargo 88509?
The Fargo 88509 features built-in Ethernet and USB 2.0 connectivity with an internal print server, enabling both centralized and remote ID card issuance. An optional single-wire Ethernet and USB 2.0 interface is also available for inline printing and encoding applications.
What software tools are included with the Fargo 88509?
The Fargo 88509 includes the FARGO Workbench diagnostic utility with Color Assist spot-color matching technology for printer maintenance and color management. It is also interoperable with Asure ID card personalization software for badge design, database management, and technology card encoding, as well as EasyLobby Secure Visitor Management Solutions.
What are the operating environmental specifications for the Fargo 88509?
The Fargo 88509 operates in temperature ranges from 65° to 80°F (18° to 27°C) with humidity tolerance of 20–80% non-condensing. The printer requires 100-240 VAC power supply at 3.3 A and supports both 50 Hz and 60 Hz frequencies.
Does the Fargo 88509 offer dual-sided printing capability?
Yes, the Fargo 88509 is available in both single-sided and dual-sided printing configurations. The dual-sided model allows for complete front-and-back card personalization, with dimensions of 9.8˝H x 18.7˝W x 9.2˝D and weighing 11 lbs.
What is the warranty coverage for the Fargo 88509?
The Fargo 88509 comes with a two-year warranty on the printer and a two-year unlimited-pass warranty on the printhead when using UltraCard consumables. Contact us today to discuss warranty options and extended coverage available from Barcodes Inc.
