Fargo 55602 ID Card Printer
Fargo Parts ID Card Printer Model Overview
Frequently Asked Questions
What encoding options does the Fargo 55602 ID Card Printer support?
The Fargo 55602 supports multiple encoding technologies including 125kHz HID PROX reader, 3.56 MHz iCLASS® (Standard/SE/SR/Seos®), MIFARE Classic™, MIFARE DESFire® EV1, and contact smart card encoding modules. It also offers optional magnetic stripe encoding capability for comprehensive credential programming flexibility.
What connectivity options are available for the Fargo 55602?
The Fargo 55602 features built-in Ethernet and USB 2.0 interfaces for centralized or remote ID card issuance. An optional Wi-Fi® module is also available, enabling flexible deployment in various network environments for inline printing and encoding operations.
What print speeds can I expect from the Fargo 55602?
Print speeds vary based on ribbon configuration: 7 seconds per card for single-color black (K), 12 seconds for black with overlay (KO), 24 seconds for full-color YMCKO, and 31 seconds for full-color with dual black panels (YMCKOK). Actual speed depends on your chosen ribbon type and card design complexity.
Is the Fargo 55602 compatible with existing card design software?
Yes, the Fargo 55602 is interoperable with Asure ID® card personalization software for badge design, database management, and technology card encoding. It also works with EasyLobby® Secure Visitor Management Solutions, providing flexibility in your ID card workflow integration.
What card types and sizes does the Fargo 55602 accept?
The printer accepts standard CR-80 cards (3.375"L x 2.125"W) with thicknesses from 20 mil to 40 mil. It supports PVC or polyester cards with polished PVC finish, as well as optical memory cards with PVC finish, accommodating diverse credential requirements.
What diagnostic and maintenance tools are included with the Fargo 55602?
The Fargo 55602 includes the FARGO Workbench™ diagnostic utility with Color Assist™ spot-color matching to facilitate printer maintenance and optimize print quality. The SmartScreen™ graphical display provides user-friendly status monitoring and operational control throughout the card issuance process.
