Evolis PM2-0010 ID Card Printer
Full specifications (PDF)
Evolis Primacy 2 ID Card Printer Model Overview
The Evolis Primacy 2 Printer is the ultimate high-performance solution for medium to large volume card printing. With blistering print speeds of up to 280 cards per hour and high-resolution capabilities, this printer produces vibrant, professional-quality cards ideal for all your identification needs. Tailor your designs with customizable graphics and various encoding options, ensuring a spectrum of security levels tailored to your requirements. The sleek, compact design paired with user-friendly features makes this printer a perfect addition to any workspace.
Key Features
- Fast Print Speeds: Up to 280 cards per hour (single-sided)
- High Resolution: 300 dpi for stunning quality
- Multiple Encoding Options: Magnetic, contact, and contactless options available
- User-Friendly Interface: LED panel or optional LCD touch screen
- Flexible Card Types: Supports PVC, PET, ABS, and rewritable cards
Specifications
- Print Technology: Color sublimation and resin thermal transfer
- Feeder Capacity: 100 cards (0.76 mm - 30 mil)
- Connectivity: USB and Ethernet; optional wireless
- Warranty: 3 years with optional extended coverage
- Dimensions: Compact and sleek design for easy integration
Frequently Asked Questions
What are the print speeds for the Evolis Primacy 2 card printer?
The Evolis Primacy 2 delivers up to 280 cards per hour for color printing on a single side, making it one of the quickest card printers on the market. For dual-sided color printing (YMCKO-K), the printer produces 140 cards per hour. Monochrome thermal transfer printing speeds range from 600 to 850 cards per hour depending on your configuration.
What encoding and security options does the Primacy 2 support?
The Evolis Primacy 2 supports multiple encoding options including magnetic stripe encoding (ISO 7811 and JIS Type II), ISO 7813 smart card contact stations, and contactless chip encoding (ISO 14443A/B, ISO 15693, MIFARE, DESfire, HID iCLASS, and Legic). Additional security features include UV effect printing, double-layer overlay lamination, and digital erasing with Kineclipse® technology to protect printed data.
What card capacity and handling does this printer support?
The Primacy 2 features a 100-card input hopper (with an optional 200-card feeder available for integration on-site), a 100-card output hopper, and a 30-card reject tray. The printer handles card thicknesses from 0.25 to 1.25 mm (10 to 50 mil) and supports ISO CR80 format cards (53.98mm x 85.60mm) in PVC, composite PVC, PET, ABS, and special varnished materials.
What connectivity options are available on the Evolis Primacy 2?
The Primacy 2 offers both USB and Ethernet connectivity options, allowing flexible integration into your network environment. The printer comes standard with a USB cable (1.80m) and supports printing from smartphones and tablets through the Evolis Premium Suite software available for Windows, Mac, and Linux platforms.
What operating and storage environment conditions does the Primacy 2 require?
The Primacy 2 operates optimally at temperatures between 15° and 30°C (59° to 86°F) with humidity levels of 20% to 65% non-condensing. For storage, the printer should be kept at temperatures between -5° and +70°C (23° to 158°F) with humidity levels of 20% to 70% non-condensing, and requires free air ventilation during operation.
What warranty and consumable support is included with the Primacy 2?
The Evolis Primacy 2 includes a 3-year warranty when using Evolis High Trust® consumables and following specific usage conditions. We offer a complete range of ribbons including color (YMCKO), monochrome metallic (silver and gold), signature panel, scratch-off, and hologram varnish options, along with starter cleaning kits and cardPresso XXS software licensing. Contact us today for consumable options and support.
