Equinox 010332-359R Payment Terminal

The Equinox 010332-359R Payment Terminal has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Equinox T4220 - Equinox Payments T4220 Payment Terminal - FSTN LCD Display - ARM ARM9 - 16 MB RAM - Triple DES, DUKPT - Fast Ethernet - Network, Modem, Serial, PIN Port - Serial - PCI PED, Pin Pad
Discontinued Need Assistance?
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Equinox T4220 Payment Terminal Model Overview
The Equinox T4220 is the most secure IP and dial-backup countertop terminal on the market today. Along with its ability to process transactions rapidly, the T4220 features an intelligent IP diagnostics application to monitor and communicate failure occurrences, locate the source of the error, and instruct the user how to repair it.
Equinox 010332-359R Payment Terminal Overview
IP Performance + Superior Security

The T4220 from Equinox Payments is designed for merchants demanding unrivaled IP transaction and download speeds combined with rock-solid security. This robust payment system comes standard with integrated PCI PTS-approved PIN entry capability and the piece of mind that comes with our proprietary Equinox Secure Architecture™ that provides unparalleled security for your transactions.

The T4220 includes 24MB of total memory, a powerful ARM9 processor for fast transactions, the ability to support multiple applications and a proprietary IP diagnostics application that clearly communicates when an error has occurred and-more importantly-how to fix it!
Technical Information
Encryption:
  • Triple DES
  • DUKPT
Pin Pad:
Yes
Processor & Chipset
Processor Manufacturer:
ARM
Processor Type:
ARM9
Memory
Standard Memory:
16 MB
Flash Memory:
8 MB
Display & Graphics
Display Screen Type:
FSTN LCD
Screen Resolution:
160 x 80
Network & Communication
Ethernet Technology:
Fast Ethernet
Interfaces/Ports
Network (RJ-45):
Yes
Serial:
Yes
Phone Line (RJ-11):
Yes
Built-in Devices
Built-in Devices:
  • Direct Thermal Printer
  • Magnetic Stripe Reader
  • Smart Card Reader
Keyboard/Keypad
Number of Keys:
25
Power Description
Input Voltage:
  • 7.5 V DC
  • 120 V AC
  • 230 V AC
Physical Characteristics
Height:
2.3"
Width:
3.6"
Depth:
8.1"
Weight (Approximate):
1.06 lb
Miscellaneous
Additional Information:
Printer:
  • SureLoad clamshell design, drop-in loading, thermal technology
  • 384 dots per line
  • Speed: 15+ lines per second
  • Paper roll: 2.25-inch, 50mm max. diameter
Approvals:
  • PCI PTS
  • EMV Level I & II
  • Interac certified
  • MasterCard PTSP approved
Certifications & Standards:
  • UL/cUL
  • FCC Part 5B
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211720
Questions? Get help from
a POS Expert!

What is your POS application?

The Equinox 010332-359R Payment Terminal is also known as 010332359R
