Epson OmniLink TM-T88V-DT Receipt Printer Model Overview
The Epson OmniLink TM-T88V-DT is an intelligent printer designed specifically for mobile and web-based POS applications. Offering a compact and retail-hardened solution, this printer integrates a PC with an Intel Atom processor and supports both POSReady 7 and Linux operating systems. With high-speed printing capabilities and print options that save up to 30% in paper usage, the TM-T88V-DT ensures efficiency without sacrificing performance. Its connectivity options, including Ethernet and optional Wireless-N, coupled with multiple USB ports, provide unparalleled flexibility for today's dynamic retail environments.
Key Features
Retail-hardened PC with integrated printer
High-speed printing up to 11.8"/sec
Flexible connectivity: Ethernet and optional Wireless-N
Supports mobile POS with web-based printing
Six USB ports for peripheral connectivity
Save on paper with options reducing usage by up to 30%
Specifications
Print Method: Thermal line printing
Print Speed: Max. 11.8"/sec for graphics and text
Operating System: POSReady 7 or Linux
Processor: Intel® Atom™ Processor (1.86GHz)
Memory: 4.0GB (DDR2-800)
Connectivity: USB 2.0 x 6, Ethernet, VGA
Dimensions: 5.71" x 10.98" x 7.20"
Weight: 7.05 lb
Warranty: 4 years for printer; 2 years for PC
MTBF: 360,000 hours
MCBF: 70,000,000 lines
Power Consumption: Approx. 1.8 A operating
Epson C31CC74742 Receipt Printer Overview
The TM-T88V POS thermal printer is the latest addition to Epson's industry-leading TM-T88 POS printer series. It offers fast printing up to 300mm/second for both text and graphics, best-in-class reliability, new ease-of-use features and dual interfaces. In addition, the TM-T88V is ENERGY STAR qualified* and offers print options that reduce paper usage up to 30%.
Printer USB Interface, Epson all printers excecpt TransScan TM-T70, TM-T70, TM-T88V & TM-T88IV, UB-U03 USB Connect-IT Interface without display module or hub port
Printer Spare Part, Epson TransScan, TM-T70, TM-T88IV, & TM-T88V, UB-U19 Connect-IT Interface Card, On-board USB with DB-9 Serial, No hub, or DM-D port
What print speed and resolution does the Epson TM-T88V-DT deliver?
The Epson TM-T88V-DT prints at 11.81 inches per second in monochrome with a resolution of 180 x 180 dpi. This combination of speed and clarity makes it ideal for high-volume retail environments where receipt throughput and readability are critical. We offer this model for immediate deployment in your POS infrastructure.
What connectivity options are available on the TM-T88V-DT?
The TM-T88V-DT includes built-in USB and Ethernet 10/100Base-T/TX interfaces, with optional wireless connectivity available. This multi-interface design allows you to integrate the printer into various network configurations—from direct USB connections to modern cloud-based POS systems. Contact us today to discuss which connectivity option best fits your deployment.
What barcode and character sets does this receipt printer support?
The TM-T88V-DT supports 1D barcodes including UPC-A/E, CODE 39/93/128, EAN8/13, ITF, and CODABAR, as well as 2D symbols such as PDF417, QR-CODE, MaxiCode, and GS1 DataBar variants. It also handles 95 alphanumeric characters, 18 international character sets, and graphics up to 128 x 43 pixels, making it versatile for retail labels, receipts, and promotional content.
What are the paper width and print width specifications?
The printer accommodates 80mm and 58mm paper widths, with a print width of 2.83 inches (approximately 72mm). For the 80mm paper option, you get 42 columns in Font A and 56 columns in Font B, providing flexible layout options for different receipt formats. Available from us with standard roll paper included.
Is the TM-T88V-DT suitable for kiosk and mobile POS applications?
Yes—the TM-T88V-DT is specifically designed for mobile POS, web-based POS configurations, and kiosk applications, as noted in its product specifications. Its compact ultra-small footprint, combined with flexible connectivity and computing power, makes it an excellent choice for self-service and distributed retail environments.
What operating system and processor does the integrated PC use?
The TM-T88V-DT includes a retail-hardened PC powered by an Intel Atom 1.8GHz processor with 4GB of memory and 16GB hard drive storage. It runs either POSReady 7 or Linux operating system, providing stability and performance optimization for demanding retail applications. Visit barcodesinc.com to configure your system with the OS that matches your POS software requirements.
The Epson C31CC74742 Receipt Printer is also known as
EPS-C31CC74742
or C31CC74742.
Full specifications (PDF)
