Epson C31C514613 Receipt Printer

Epson's TM-U220: TM-U220A, TM-U220B, TM-U220D printers are the enhanced, more powerful successors to Epson's best-selling TM-U200 family.

All three printer models in the Epson TM-U220: TM-U220A, TM-U220B, TM-U220D series are optimized for high-speed throughput so customer receipts and kitchen orders print faster than ever. For maximum efficiency, the TM-U220 A (with journal take-up and auto-cutter), TM-U220 B (with auto-cutter only) and TM-U220 D (no options) all offer drop-in paper loading and two-color, black and red printing to highlight special offers and print more visible logos, and an adjustable paper width feature that allows you to use 58, 70 or 76 mm paper rolls for more flexibility and greater cost savings.

Technical Information

Data Buffer:
- 4KB
- 4 KB
Print Speed: 6 lps
Column Capacity: 40/42 column(s)
Print Method: Impact
Print Head Type: 9 Pin Dot Matrix
Input Voltage: 24 V DC
Power Supply: Included
Reliability:
- 180000 Hour(s) MTBF
- 18000000 lines MCBF

General Information

Manufacturer:
- Epson
- Epson Corporation
Product Name: TM-U220B Receipt Printer

Physical Characteristics

Color: White
Dimensions:
- 138.5mm (5") x 160mm (6") x 248mm (10")
- 138.5mm (5") x 160mm (6") x x 248mm (10")
Weight: 2.5 kg (5.51 lb)

Included Features

Included Features: Auto-cutter

Agency Approvals

Agency Approvals:
- VCCI Class A
- FCC Class A
- CE Marking
- AS/NZS 3548 Class B
- UL
- CSA
- TUV (EN60950)

Other

Package Contents:
- TM-U220B Receipt Printer
- Ribbon: ERC-38
Additional Information: Traditional Chinese Language

Warranty

Manufacturer Warranty: 2 Year(s)

Full specifications (PDF)

See all Epson TM-U220: TM-U220A, TM-U220B, TM-U220D options »

Brand	Epson
Model	TM-U220: TM-U220A, TM-U220B, TM-U220D
Interface	No Interface
Print Method	Impact
Cutter Option	Auto-Cutter
Color	White
Form Factor	Desktop
