Epson TM-L90 – Barcode Label Printer – 203 dpi

Part Number: C31C414A8901
Model: TM-L90

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Print Resolution
203 dpi

Product Description:

  Epson TM-L90 Direct Thermal Printer - Monochrome - Dark Gray - Desktop - Label Print - Ethernet - USB - 3.50" Print Width - 5.91 in/s Mono - 203 x 203 dpi - Liner-free Label - 3.15" Label Width

Epson TM-L90 Barcode Label Printer Model Overview

Epson's Compact Thermal Printer, the TM-L90 Liner-free Compatible Label Printer, is designed for fast and efficient printing of liner-free labels and receipts, making it the perfect solution for quick-service restaurants (QSRs) and food service environments. Enjoy the benefit of cost-effective, high-speed printing at up to 170mm/second, ensuring that order accuracy and customer satisfaction are optimized. Its compatibility with NCR's Receipt on Label (ROL) media guarantees reliable, food-safe prints that adhere firmly without the hazards of traditional adhesive labels.

Key features:
  • Cost-effective liner-free label printing for quick-service restaurants and food services.
  • Fast printing speeds of up to 170mm/second for receipts and 90mm/second for labels.
  • Supports multiple interfaces including serial, parallel, Ethernet, USB, and wireless.
  • Reduces media costs with top margin reduction, minimizing waste.
  • One-year limited warranty backed by Epson’s industry-leading service and support.

Specifications:
  • Print method: Thermal line
  • Print resolution: 203 x 203 dpi
  • Print speed: 170mm/second (receipts), 90mm/second (label media)
  • Paper width: 40mm or 80mm
  • Paper diameter: Up to 4" (102mm)
  • Power consumption: Approx. 1.7A (mean)
  • Reliability: MTBF 360,000 hours, MCBF 70 million lines for receipts
  • Overall dimensions: 203(H) x 140(W) x 148(D)mm (8.0" x 5.5" x 5.8")
  • Weight: Approx. 1.9 kg (4.18 lbs)
Epson C31C414A8901 Barcode Label Printer Overview

This high quality printer offers fast label and barcode printing in one compact unit. With its software utility you can quickly design custom labels and barcodes and print in one- or two-colors on a variety of print stocks. It supports continuous printing on liner labels and cost-effective one- and two-color thermal labels are available from Epson in a variety of sizes.

Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
5.91 in/s
Maximum Print Resolution (dpi):
203 x 203
Number of Columns:
72
Maximum Print Width:
3.50"
Barcode Symbology Supported:
  • UPC-A
  • UPC-E
  • JAN-13
  • JAN-8
  • ITF
  • Codabar
  • Code 128
  • Code 39
  • Code 93
  • PDF-417
  • Maxi Code
  • QR Code
Application/Usage:
Desktop
Features:
Auto-cutter
Print Technology:
Direct Thermal
Memory
Standard Memory:
4 KB
Interfaces/Ports
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Cutter
Cutter:
Yes
Media Types & Handling
Media Type:
Liner-free Label
Maximum Roll Diameter:
3.54"
Maximum Label Width:
3.15"
Power Description
Power Source:
Power Adapter
Input Voltage:
24 V DC
Physical Characteristics
Color Family:
Gray
Product Color:
Dark Gray
Height:
8"
Width:
5.5"
Depth:
5.8"
Weight (Approximate):
4.19 lb
Miscellaneous
Platform Supported:
PC
Certifications & Standards:
  • VCCI class A
  • FCC class A
  • CE marking
  • Canada EMI
  • AS/NZS 3548
  • UL
  • CSA
  • TUV (EN60950)
Environmentally Friendly:
Yes
Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
Item Numbers
UNSPSC: 45101512
