Full specifications (PDF)
Bluetooth:
Yes
Bluetooth Standard:
Bluetooth 5.0
Elo E814281 POS System
Part Number:
E814281
Model:
Pay 7"
Elo Pay 7" POS System Model Overview
The Elo Pay 7-inch Integrated Payment POS System is designed for merchants seeking a compact, enterprise-grade terminal without compromising on performance or versatility. Boasting a vibrant 7-inch HD touch display and powered by a Qualcomm Snapdragon 660 processor, it efficiently supports all payment methods, including EMV, NFC, and pin-on-glass. Its modular design allows for flexible mounting options, making it suitable for various retail environments. With seamless management through EloView, merchants can effortlessly deploy content and maintain settings, ensuring a streamlined transaction experience for both customers and staff.
Key Features
- Compact 7-inch HD Touch Display for clear visibility
- Integrated Payment Options support all payment types
- Modular Design with flexible mounting configurations
- Powered by Android 12 for enhanced functionality
- Enterprise-Grade Support with security updates and management tools
Specifications
- Diagonal Size: 7"
- Resolution: 1920 x 1080
- Brightness: 400 nits
- Operating System: Android 12
- Processor: Qualcomm Snapdragon 660, 2.2GHz Octa-Core
- Memory: 4GB
- Storage: 64GB (expandable via MicroSD)
- Wireless: 802.11a/b/g/n/ac, Bluetooth 5.0
- Dimensions: 6.9" x 6.6" x 1.7"
- Weight: 1.4 lbs
- Operating Temperature: 32°F to 104°F
- Warranty: 2 years standard
Elo E814281 POS System Overview
The Elo Pay 7-inch integrated payment POS system packs the modularity merchants need into a compact enterprise-grade terminal. Complete with a 7-inch HD touch display, integrated payment, flexible Android 12 OS and Qualcomm SD660 processor. From EMV and NFC to MSR and support for pin-on-glass, the Elo Pay 7-inch POS system supports all forms of payment. And with the ability to place it on the counter, mount it on the printer stand or integrate it on the back of the Z70 POS Stand, there is a configuration to support all types of merchants.
Start changing the way customers and employees interact by deploying a new generation of interactive technologies that provides seamless integration, effortless provisioning and simplified device management via EloView or your preferred management tools.
With Elo Pay terminals built on a common kernel, a single integration provides you with access to Elo's entire payment terminal lineup
Enterprise-Grade Support - Security updates, seamless provisioning, Elo Home, OEMConfig and more
Deploy content, manage settings and maintain the OS with EloView
Modular design with flexible mounting
Technical Information
Processor & Chipset
Processor Type:
Snapdragon
Processor Core:
Octa-core (8 Core)
Processor Speed:
2.20 GHz
Processor Model:
SD660
Memory
Standard Memory:
4 GB
Memory Card Slot:
Yes
Memory Card Supported:
microSD
Storage
Flash Memory Capacity:
64 GB
Display & Graphics
Screen Size:
7"
Display Screen Type:
LCD
Screen Mode:
Full HD
Touchscreen:
Yes
Touchscreen Technology:
Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touch Points:
10
Contrast Ratio:
1,000:1
Network & Communication
Wireless LAN:
Yes
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
USB:
Yes
USB Type-C:
Yes
Network (RJ-45):
Yes
Serial Port:
Yes
Number of USB Type A Ports:
4
Number of USB Type C Ports:
2
Built-in Devices
Number of Speakers:
1
Speaker Power:
1 W
Magnetic Stripe Reader:
Yes
Software
Operating System:
Android 12
Power Description
Power Source:
DC Power
Physical Characteristics
Color Family:
Black
Product Color:
Black
Height:
6.6"
Width:
6.9"
Depth:
1.7"
Weight (Approximate):
1.40 lb
Miscellaneous
Ingress Protection (IP) Rating:
IP54
Item Numbers
GTIN:
0843173155104
UPC:
843173155104
EAN:
0843173155104
Recommended Accessories
Category
- Pos Workstation Accessories (3)
Recommended Accessories for Model: Elo E814281 POS System
Top Pos Workstation Accessories Purchased With Elo E814281
-
Elo E815044 POS SuppliesPOS Supplies, Elo Pay 7", Small I/O Hub: 1x DC-in, 1x RJ45 LAN, 4x USB-A, 2x USB-CIn Stock$334.76 -
Elo E815235 POS SuppliesPOS Supplies, Elo Pay 7", Large I/O Hub: 1x DC-in, 1x RJ45 LAN, 1x RJ12 Cash Drawer, 4x USB-A, 2x USB-C, 1x Powered USB (24V)Item on backorder — chat for lead time$526.31 -
Elo E220684 POS SuppliesPOS Supplies, Elo Pay 7", VESA Mount KitItem on backorder — chat for lead time$39.10
Frequently Asked Questions
What payment methods does the Elo E814281 POS System support?
The Elo Pay 7-inch supports all major payment forms including EMV, NFC/contactless, magstripe (MSR), and PIN-on-glass transactions. This comprehensive payment support enables merchants to accept dip, tap, and swipe payments, making it compatible with Apple Pay, Google Pay, Samsung Pay, and all major card networks including Visa, Mastercard, American Express, and Discover.
What are the mounting and deployment options for the Elo E814281?
The Elo Pay 7-inch features a modular design with flexible mounting options to suit different retail environments. You can place it on the counter, mount it on a printer stand, or integrate it on the back of the Z70 POS Stand, giving you the configuration you need for your specific merchant setup.
What operating system and processor does this POS system run?
The Elo E814281 runs Android 12 with Google Mobile Services (GMS) and is powered by a Qualcomm SD660 octa-core processor. This combination provides reliable performance and access to the full Android ecosystem for POS applications and services.
How is the Elo E814281 managed and updated in a multi-terminal environment?
The Elo Pay 7-inch is managed through EloView, which allows you to deploy content, manage settings, and maintain the operating system across your devices. Since all Elo Pay terminals share a common kernel, a single integration gives you access to Elo's entire payment terminal lineup, and the system includes enterprise-grade support with security updates and seamless provisioning.
What are the display and storage specifications of the Elo E814281?
The Elo E814281 features a 7-inch HD touchscreen display with 1920 x 1080 resolution. It includes 4GB of RAM and 64GB of internal flash storage, which is expandable via microSD card for additional capacity when needed.
What connectivity options does the Elo Pay 7-inch POS System offer?
The Elo E814281 provides wireless connectivity via 802.11a/b/g/n/ac Wi-Fi and Bluetooth 5.0, enabling flexible integration with your retail network and peripherals. The system comes with a 2-year standard warranty and operates reliably in temperatures from 32°F to 104°F.
The Elo E814281 POS System is also known as
ELO-E814281
or E814281.
