Elo E802828 Touchscreen

Elo 2020L - 20" LCD IntelliTouch (surface wave), USB, Desktop, Active matrix TFT. Color: Black
Designed for retail POS, industrial, and government applications, as well as interactive digital signage.

The 2020L touchmonitor is designed for retail POS, industrial, and government applications as well as interactive digital signage. It is available with AccuTouch Five-Wire Resistive Technology and serial interface. 2020L has a high-quality panel with 178 degree viewing angle. It can be used in portrait mode and also has an adjustable height. It has a carrying handle for easy transport and a quick release stand.

Technical Information

  • Horizontal Viewing Angle: 178°
  • Vertical Viewing Angle: 178°
  • Adjustable Display Angle: Yes
  • Adjustable Display Height: Yes
  • Adjustable Display Pivot: Yes
  • Display Orientation: Landscape/Portrait
  • Features: Digital Signage Ready
  • Mount Type:
    • Desk Mountable
    • Wall Mountable
  • Screen Size: 20.1"
  • Aspect Ratio: 4:3
  • Response Time: 16 ms
  • Screen Surface: Anti-glare

General Information

  • Product Type: LCD Touchscreen Monitor
  • Brand Name: Elo
  • Manufacturer: Elo Touch Solutions, Inc
  • Product Model: 2020L
  • Product Name: 2020L 20-Inch Desktop/Wall-Mount Touchmonitor

Physical Characteristics

  • Weight with Stand (Approximate): 24.25 lb
  • VESA Mount Compatible: Yes
  • VESA Mount Standard: 100 x 100
  • Height with Stand: 22.28"
  • Width with Stand: 17.28"
  • Depth with Stand: 9.72"
  • Color: Black

Interfaces/Ports

  • USB: Yes
  • DVI: Yes
  • VGA: Yes

Other

  • Green Compliant: Yes
  • Green Compliance Certificate/Authority: RoHS
  • Certifications & Standards:
    • FCC
    • CE
    • UL
    • FCC
    • CE
    • UL

Video

  • Standard Refresh Rate: 60 Hz
  • Brightness: 280 Nit
  • Color Supported: 16.7 Million Colors
  • Maximum Resolution: 1600 x 1200
  • Contrast Ratio: 700:1

Power Description

  • Operating Power Consumption: 50 W
  • Input Voltage:
    • 110 V AC
    • 220 V AC

Touchscreen Information

  • Touchscreen: Yes
  • Touchscreen Type: IntelliTouch Surface Wave

Warranty

  • Limited Warranty: 3 Year
Brand Elo
Model 2020L
Screen Size 20
Touch Technology Surface Wave
Display Type LCD
Form Factor Desktop
Color Black
Interface USB
