Elo E796382 Touchscreen

Part Number: E796382
Model: 0702L
Add to My Shopping List Add to Compare
$334.81
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
7"
Viewable Screen Size
7"
Screen Mode
WVGA
Panel Technology
Thin Film Transistor (TFT)

Product Description:

  7" Touchscreen Monitor, Elo 0702L, Desktop LCD, 5:3 Aspect Ratio, Projected Capacitive 10-Touch, 800 x 480, 16.2 million Colors, 430 nits Brightness (typical), 500:1 Contrast Ratio (typical), DisplayLink Input, USB Touch Controller Interface, Anti-Glare, Zero-Bezel, Black, 3-Year Warranty, Worldwide. Box Includes Micro USB Y-Cable (Part# E796577) and Quick Install Guide.
Explore all Elo 0702L Touchscreens
Add to Quote
Elo E796382 Touchscreen
Elo E796382 Touchscreen
Elo E796382 Touchscreen
Elo E796382 Touchscreen
Elo E796382 Touchscreen
Elo E796382 Touchscreen
Elo E796382 Touchscreen Elo E796382 Touchscreen Elo E796382 Touchscreen Elo E796382 Touchscreen Elo E796382 Touchscreen Elo E796382 Touchscreen
Full specifications (PDF)

Elo 0702L Touchscreen Model Overview

The Elo 0702L 7-inch touchscreen monitor offers a sleek and responsive interactive solution for various commercial applications, including point-of-sale, brand loyalty, and hospitality installations. Featuring Elo's innovative Touch Pro® PCAP technology, this monitor supports up to 10 simultaneous touches, ensuring a seamless user experience. With its minimal design and edge-to-edge glass, the 0702L integrates effortlessly into any environment. Backed by a 3-year warranty and equipped with DisplayLink technology for simple connectivity, this monitor is ideal for both customer-facing and industrial applications.

Key features:
  • 7-inch LCD with edge-to-edge design for a modern look
  • Integrated 10-touch capability for enhanced interactivity
  • DisplayLink technology allows for power, video, and touch over a single cable
  • Versatile mounting options with VESA compatibility
  • 3-year warranty for peace of mind


Specifications:
  • Color: Black
  • Diagonal Size: 7"/177.8 mm
  • Active Touch Area: 6.07" x 3.38" / 154.08 mm x 85.92 mm
  • Touch Technology: TouchPro PCAP (10 touches)
  • Native Resolution: 800 x 480
  • Brightness: 430 nits with TouchPro PCAP
  • Dimensions: 4.61" x 7.11" x 0.7" / 117.22 mm x 180.58 mm x 17.7 mm
  • Weight: Unpackaged - 0.77 lbs / 0.35 kg
  • Operating Temperature: 0°C to 40°C / 32°F to 104°F
  • Warranty: 3 years
Elo E796382 Touchscreen Overview

Elo's 0702L Touchscreen Monitor

The Elo 0702L 7-inch touchscreen monitor offers the same seamless design that spans the entire Elo 02-Series lineup. With a form factor only half an inch thin and a design tailored for ease of integration, the 0702L thrives in customer-facing installations in point-of-sale, brand-loyalty, point-of- information, signage and hospitality applications. With a slim footprint, the 0702L is also well-suited for industrial kitchen equipment controllers and kitchen display systems.

Single-Cable Connection

Using DisplayLink technology, the 0702L provides a single-cable solution that combines power, video and touch signals into one USB connection. By reducing the number of cables from 3 to 1, installation is a breeze, and you never have to worry about a power adapter again.

DisplayLink technology supports Windows, Android and Linux operating systems.

Mount With Flexibility

Customers demand a seamless shopping experience from the moment they enter the store through check-out. From stands and pole mounts to shelf mounts, wall mounts and 3rd-party VESA mounts, the touchscreens can be integrated with ease.

Brilliant Displays from 7 to 27-inches

The brilliant touchscreens with Elo's industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution and light transmission for accurate touch response and vivid images. Capable of handling up to 10 simultaneous touches, the 02-Series touchscreen monitors provide an enhanced tablet-like experience.

EloCareSM - We Have Your Back

When a technology outage happens, retailers, restaurants and business operators want to know the right person to call, right away. EloCare offers services you can count on in case the unexpected happens.

Full specifications (PDF)
Technical Information
Screen Size Class:
7"
Viewable Screen Size:
7"
Screen Mode:
WVGA
Panel Technology:
Thin Film Transistor (TFT)
Response Time:
25 ms
Response Time Details:
25 ms Typical
Aspect Ratio:
5:3
Horizontal Viewing Angle:
150°
Vertical Viewing Angle:
120°
Mount Type:
  • Pole Mount
  • Shelf Mount
  • Wall Mountable
Backlight Technology:
LED
Features:
Anti-glare
Horizontal Frequency:
31.50 kHz
Vertical Frequency:
60 Hz
Video
Maximum Resolution:
800 x 480
Color Supported:
16.2 Million Colors
Native Contrast Ratio:
500:1
Brightness:
500 Nit
Touchscreen Information
Touchscreen Type:
TouchPro Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
10
Interfaces/Ports
USB:
Yes
Number of USB Ports:
1
Power Description
Operating Power Consumption:
3.70 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
75 x 75
Color Family:
Black
Product Color:
Black
Height:
4.6"
Width:
7.1"
Depth:
0.7"
Weight (Approximate):
12.32 oz
Miscellaneous
Package Contents:
  • 0702L 7" Touchscreen Monitor
  • Micro USB Y-cable
  • Quick Install Guide
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0818289649229, 0843173110721
UPC: 818289649229, 843173110721
EAN: 0818289649229, 0843173110721
UNSPSC: 43211903

Recommended Accessories

Category

  • Pos Workstation Accessories (1)
  • Touchscreen Accessories (6)

Recommended Accessories for Model: Elo E796382 Touchscreen

Top Pos Workstation Accessories Purchased With Elo E796382

Top Touchscreen Accessories Purchased With Elo E796382

  • Elo E047663 Accessory
    Elo E047663 Accessory
    Mounting Hardware & Stands, ELO, Accessory 12-Inch Pole Mount Kit for I-Series and M-Series
    In Stock
    $207.51
    Add to Quote
  • Elo E160104 Accessory
    Elo E160104 Accessory
    Mounting Hardware & Stands, ELO, Accessory Table Top Stand for the 1002L and 10I
    In Stock
    $172.93
    Add to Quote
  • Elo E047864 Accessory
    Elo E047864 Accessory
    Mounting Hardware & Stands, ELO, Bolt Down 18-Inch Pole Mount Kit for I-Series and M-Series Monitors
    Item on backorder — chat for lead time
    $237.60
    Add to Quote
See All Touchscreen Accessories for Elo E796382 Touchscreen >

Frequently Asked Questions

The Elo 0702L features Elo's industry-leading TouchPro PCAP (projected capacitive) technology that supports up to 10 simultaneous touches. This advanced touch technology enables responsive, multi-touch interactions ideal for customer-facing applications and interactive installations.

The Elo 0702L supports Windows, Android, and Linux operating systems through its DisplayLink technology. This multi-platform compatibility makes it a versatile choice for diverse deployment environments across different IT infrastructures.

The Elo 0702L uses DisplayLink technology to deliver power, video, and touch over a single cable, reducing installation complexity from 3 cables to just 1. This unified connection eliminates the need for a separate power adapter and makes setup and integration significantly easier.

The Elo 0702L is purpose-built for point-of-sale, brand-loyalty, point-of-information, signage, and hospitality applications. Its compact 7-inch form factor and minimal footprint also make it well-suited for industrial kitchen equipment controllers and other space-constrained environments.

The Elo 0702L delivers 800 x 480 resolution with 16.2 million colors and a 5:3 aspect ratio. With 430 nits typical brightness and a 500:1 contrast ratio, it provides clear visibility and professional image quality for interactive customer-facing displays.

The Elo 0702L is backed by a three-year warranty and features a sleek, modern design with an edge-to-edge glass front and zero-bezel construction. At only half an inch thin, it delivers a professional appearance while maintaining an extremely compact footprint for flexible installation options.

The Elo E796382 Touchscreen is also known as ELO-E796382 or E796382.
