Elo E537168 Touchscreen

Part Number: E537168
Model: 1715L

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
17"
Viewable Screen Size
17"
Screen Mode
SXGA
Response Time
25 ms

Product Description:

  Elo 1715L 17" LCD Touchscreen Monitor - 5:4 - 25 ms - 17" Class - 5-wire Resistive - 1280 x 1024 - SXGA - 16.2 Million Colors - 450:1 - 250 Nit - USB - VGA - Gray

Elo 1715L Touchscreen Model Overview

The Tyco Electronics 1715L 17" LCD Desktop Touchmonitor offers an entry-level touch solution without compromising on Elo's renowned quality and reliability. Designed specifically for touch applications from the ground up, this monitor features a sturdy tilt base, side controls for easier accessibility, and a lockout function for public use. With its compact design, the 1715L can be mounted on desktops or walls, making it ideal for various settings. Enhanced with IntelliTouch surface-wave technology, it ensures exceptional touch responsiveness while remaining sealed against dust, dirt, and liquids.


Key Features:

  • Designed for touch with stable tilt base and side controls
  • Space-saving design, suitable for desktop or wall mounting
  • Factory-sealed screen protects against dirt, dust, and liquids
  • IntelliTouch surface-wave technology for superior touch performance
  • VESA mount option for flexible installation
  • Three-year warranty for peace of mind in the U.S.

Specifications:

  • Case/Bezel Color: Dark gray
  • Display Type: Active matrix TFT LCD
  • Display Size: 17" diagonal
  • Aspect Ratio: 5 x 4
  • Optimal Resolution: 1280 x 1024
  • Brightness: 250 cd/m² (230 cd/m² with touchscreen)
  • Weight: 15.2 lb (6.9 kg)
  • Power Supply: 100-240 VAC, 50/60 Hz
  • Operating Temperature: 0°C to 40°C
  • Warranty: 3 years in the U.S.
  • Agency Approvals: UL, FCC, CE, TÜV-GS, and others
Technical Information
Screen Size Class:
17"
Viewable Screen Size:
17"
Screen Mode:
SXGA
Response Time:
25 ms
Aspect Ratio:
5:4
Horizontal Viewing Angle:
140°
Vertical Viewing Angle:
123°
Video
Maximum Resolution:
1280 x 1024
Color Supported:
16.2 Million Colors
Contrast Ratio:
450:1
Brightness:
250 Nit
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
5-wire Resistive
Interfaces/Ports
USB:
Yes
VGA:
Yes
Power Description
Operating Power Consumption:
50 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Product Color:
Gray
Height:
14.4"
Width:
15.4"
Depth:
8"
Weight (Approximate):
15.20 lb
Item Numbers
GTIN: 0074114930799, 0741149301435, 0818272817819, 7411493014352
UPC: 074114930799, 741149301435, 818214096302, 818272817819
EAN: 0074114930799, 0741149301435, 0818272817819, 7411493014352
UNSPSC: 43211903

Recommended Accessories

Category

  • Touchscreen Accessories (3)

Recommended Accessories for Model: Elo E537168 Touchscreen

Top Touchscreen Accessories Purchased With Elo E537168

Questions? Get help from
a POS Expert!

What is your POS application?

The Elo E537168 Touchscreen is also known as ELO-E537168 or E537168.
