Elo E351600 Touchscreen

Part Number: E351600
Model: 2202L
Add to My Shopping List Add to Compare
$630.14
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
22"
Viewable Screen Size
21.5"
Screen Mode
Full HD
Panel Technology
Thin Film Transistor (TFT)

Product Description:

  22" Touchscreen Monitor, Elo 2202L, Desktop LCD, 16:9 Aspect Ratio, Projected Capacitive 10-Touch, 1920 x 1080/Full HD, 16.7 million Colors, 225 nits Brightness (typical), 1000:1 Contrast Ratio (typical), USB Touch Controller Interface, Clear, Zero-Bezel, Stand, Black, 3-Year Warranty, Speakers, Worldwide. Box Includes Quick Install Guide, 3x Tie Wraps, VGA Cable, HDMI Cable, Touch USB Cable (Part# E408193), Audio Cable, Power Brick (Part# E593661), NA Power Cable, EU Power Cable, EEI Label.
Explore all Elo 2202L Touchscreens
Add to Quote
Elo E351600 Touchscreen
Elo E351600 Touchscreen
Elo E351600 Touchscreen
Elo E351600 Touchscreen
Elo E351600 Touchscreen
Elo E351600 Touchscreen
Elo E351600 Touchscreen Elo E351600 Touchscreen Elo E351600 Touchscreen Elo E351600 Touchscreen Elo E351600 Touchscreen

Full specifications (PDF)

Elo 2202L Touchscreen Model Overview

The Elo 2202L 22" touchscreen monitor delivers a professional-grade interactive solution with Elo's industry-leading TouchPro PCAP technology featuring edge-to-edge glass and enabling up to 10 simultaneous touches. The clear glass touchscreen provides exceptional image clarity, resolution, and light transmission for vivid images and details. Backed by a three-year warranty, the feature rich touchscreen monitor is equipped with dual built-in speakers and VGA and HDMI video connectors. With a compact form factor, clean design aesthetic, and flexible mounting options, these touchscreens are well-suited for POS, interactive digital signage and self-service.
Elo E351600 Touchscreen Overview

2202L Touchscreen Monitor

The Elo 02-Series of Touchscreen Monitors designed with seamless style across all sizes includes four options - a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint.

Brilliant Displays from 19 to 27-inches

The clear glass touchscreens with Elo's industry-leading TouchPro® PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience.

Well-Suited for...

Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.

Connect your Accessories

From a barcode scanner to an EMV, Elo's 02-Series Monitors are compatible with a large set of peripherals purpose-built for commercial applications.

Fingerprint Reader

The Biometric Fingerprint Reader can be attached to provide secure and quick login.

MSR

Elo offers the flexibility of integrating payment devices, including a Magtek 3-track encryptable MSR payment terminal.

Barcode Scanner

Enhance self-service checkout and price-checker applications by coupling a high-performance barcode scanner onto the Elo touchscreen.

NFC

The Near Field Communication (NFC) adapter can be integrated for easy mobile payments with just a touch of the phone.

Privacy Matters

Optional privacy screens can help provide a physical safeguard for private information or sensitive data from the view of others. Whether you are the employee or the customer, privacy matters.

One for You. One for Your Customers.

Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion.

Privacy Matters

Optional privacy screens can help provide a physical safeguard for private information or sensitive data from the view of others. Whether you are the employee or the customer, participate in loyalty programs or see the latest promotion.

Mount with Flexibility

Customers demand a seamless shopping experience from first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party VESA mounts, the touchscreens can be integrated with ease.

Full specifications (PDF)
Technical Information
Screen Size Class:
22"
Viewable Screen Size:
21.5"
Screen Mode:
Full HD
Panel Technology:
Thin Film Transistor (TFT)
Response Time:
14 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Mount Type:
  • Wall Mountable
  • Pole Mount
  • Shelf Mount
Placement:
Tabletop
Backlight Technology:
LED
Features:
  • On-screen Display (OSD)
  • Cable Lock Slot
Horizontal Frequency:
30 kHz to 82 kHz
Vertical Frequency:
50 Hz to 75 Hz
Curved Screen:
No
Video
Maximum Resolution:
1920 x 1080
Color Supported:
16.7 Million Colors
Contrast Ratio:
3,000:1
Native Contrast Ratio:
1,000:1
Brightness:
250 Nit
Maximum Refresh Rate:
75 Hz
Audio
Speakers:
Yes
Number of Speakers:
2
Speaker Output Power:
4 W
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
TouchPro Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
10
Interfaces/Ports
HDMI:
Yes
USB:
Yes
USB Standard:
USB 2.0
VGA:
Yes
Built-in Devices
Built-in Devices:
USB Hub
Power Description
Operating Power Consumption:
22.50 W
Standby Power Consumption:
690 mW
Off-Mode Power Consumption:
320 mW
Input Voltage Range:
100V to 240V
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Color Family:
Black
Product Color:
Black
Height:
12.9"
Width:
20.7"
Depth:
1.7"
Height with Stand:
15.11"
Width with Stand:
20.74"
Depth with Stand:
7.61"
Weight (Approximate):
10.47 lb
Weight with Stand (Approximate):
14.88 lb
Miscellaneous
Package Contents:
  • 2202L 22" Touchscreen Monitor
  • Japanese Language Regulatory Information Pamphlet
  • Quick Install Guide
  • 3 x Tie Wraps
  • VGA Cable
  • HDMI Cable
  • Touch USB Cable
  • Audio Cable
  • Power Brick
  • Power Cable
  • EEI Label
Mean Time Between Failures (MTBF):
5.7 Year
TAA Compliant:
No
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0696449969109, 0696552137938, 0719832363435, 0815335026409, 4973163119338
UPC: 696449969109, 696552137938, 719832363435, 815335026409
EAN: 0696449969109, 0696552137938, 0719832363435, 0815335026409, 4973163119338
UNSPSC: 43211903

Recommended Accessories

Category

  • 2D Barcode Scanner (2)
  • Best Barcode Scanner (2)
  • Elo Point of Sale System (1)
  • POS Monitor Accessories (2)
  • Pos Workstation Accessories (5)
  • Temperature Kiosk (1)
  • Touchscreen Accessories (9)
  • Webcams (2)

Recommended Accessories for Model: Elo E351600 Touchscreen

Top 2D Barcode Scanner Purchased With Elo E351600

  • Elo E384627 Barcode Scanner
    Elo E384627 Barcode Scanner
    Barcode Scanner, Elo Edge Connect, 2D Barcode Scanner, Performance Model, Zebra SE4720 Scan Engine, Compatible With Various ELO Touchscreens
    In Stock
    $401.40
    Add to Quote
  • Elo E245047 Barcode Scanner
    Elo E245047 Barcode Scanner
    Barcode Scanner, Elo Edge Connect, 2D Barcode Scanner, Value Model, Zebra SE4107 Scan Engine, Compatible With Various ELO Touchscreens
    In Stock
    $293.33
    Add to Quote

Top Best Barcode Scanner Purchased With Elo E351600

  • Elo E384627 Barcode Scanner
    Elo E384627 Barcode Scanner
    Barcode Scanner, Elo Edge Connect, 2D Barcode Scanner, Performance Model, Zebra SE4720 Scan Engine, Compatible With Various ELO Touchscreens
    In Stock
    $401.40
    Add to Quote
  • Elo E245047 Barcode Scanner
    Elo E245047 Barcode Scanner
    Barcode Scanner, Elo Edge Connect, 2D Barcode Scanner, Value Model, Zebra SE4107 Scan Engine, Compatible With Various ELO Touchscreens
    In Stock
    $293.33
    Add to Quote

Top Elo Point of Sale System Purchased With Elo E351600

Top POS Monitor Accessories Purchased With Elo E351600

  • Elo E804330 Accessory
    Elo E804330 Accessory
    Mounting Hardware & Stands, ELO, 24 and 27-Inch Replacement Stand, 02-/03-Series Desktop Monitors, Color: Black
    Item on backorder — chat for lead time
    $201.50
    Add to Quote
  • Elo E593865 Accessory
    Elo E593865 Accessory
    Power Systems & Supplies, ELO, NA Power Cord, 02-/03-Series Desktop Monitors
    In Stock
    $45.11
    Add to Quote

Top Pos Workstation Accessories Purchased With Elo E351600

See All Pos Workstation Accessories for Elo E351600 Touchscreen >

Top Temperature Kiosk Purchased With Elo E351600

  • Elo E534879 Temperature Kiosk
    Elo E534879 Temperature Kiosk
    Temperature Kiosk, ELO Temperature Sensor Pro, USB, Android/Windows/Linux, 5MP Camera Resolution, Automated Screening/Facial Recognition/Temperature Measurement, Self-Service/Access Control, Black, Box Includes IR Camera, 2 Mounting Screws, 2 Mylar Screw Covers, 1 Extended Micro-USB Cable, Quick Install Guide.
    Item on backorder — chat for lead time
    $1,230.00
    Add to Quote

Top Touchscreen Accessories Purchased With Elo E351600

  • Elo E001002 Accessory
    Elo E001002 Accessory
    Card Reader, ELO, Magnetic Stripe Reader, Encryptable, Color: Black, Compatible with ELO X Series
    In Stock
    $172.73
    Add to Quote
  • Elo E043382 Accessory
    Elo E043382 Accessory
    Mounting Hardware & Stands, ELO, Shelf Mount Bracket I-Series and 02 Series
    Item on backorder — chat for lead time
    $133.83
    Add to Quote
  • Elo E611864 Accessory
    Elo E611864 Accessory
    Backpack, Android 7.1, ARM A53 2.0-GHZ Octa-Core Processor, 2GB RAM, 16GB Flash, HDMI Out, Wi-Fi, Ethernet, 2X USB, GPIO, ELO View Compatible, Worldwide
    Item on backorder — chat for lead time
    $502.00
    Add to Quote
See All Touchscreen Accessories for Elo E351600 Touchscreen >

Top Webcams Purchased With Elo E351600

  • Elo E134699 Webcam
    Elo E134699 Webcam
    Webcam, ELO Elo Edge Connect 3D Camera, 3D, 1280 x 800 @ 30fps/640 x 400 @ 60fps, 0.82 ft to 4.92 ft Focus Range, Facial Recognition/Facial Authentication/Gesture Tracking, Self-Service/Access Control/Augmented Reality/Virtual Reality, Black, Box Includes 2 Mounting Screws, 2 Mylar Screw Covers, Quick Install Guide.
    In Stock
    $545.70
    Add to Quote
  • Elo E201494 Webcam
    Elo E201494 Webcam
    Webcam, ELO Elo Edge Connect Webcam, 2D, 8 MP (3264 x 2448)/Full HD (1920 x 1080)/HD (1280 x 720)/VGA (640 x 480), 3.8 ft to 13 ft Focus Range, Facial Recognition, Self-Service/Virtual Assistant/Augmented Reality, Auto Focus, Micro USB, Black, Box Includes 2 Mounting Screws, 2 Mylar Screw Covers, Quick Install Guide.
    In Stock
    $248.11
    Add to Quote

Frequently Asked Questions

The Elo 2202L 22" Touchscreen Monitor features Elo's industry-leading TouchPro PCAP (Projected Capacitive) technology with edge-to-edge glass and support for up to 10 simultaneous touches. This technology delivers responsive, multi-touch capability ideal for interactive point-of-sale and hospitality applications.

The Elo 2202L delivers a 1920 x 1080 Full HD resolution with a 16:9 wide aspect ratio, 16.7 million colors, 225 nits brightness (typical), and a 1000:1 contrast ratio (typical). The clear glass touchscreen provides exceptional image clarity and light transmission for vivid, detailed visuals.

The Elo 2202L includes VGA and HDMI video connectors, dual built-in speakers, and an integrated USB 2.0 hub for easy peripheral integration. Available accessories include MSR, barcode scanner, fingerprint reader, NFC, customer-facing display, and handles, with support for third-party peripherals as well.

The Elo 2202L is purpose-built for point-of-sale, point-of-information, signage, and hospitality applications. Its compact form factor, clean design, and energy efficiency make it well-suited for commercial environments requiring interactive customer engagement and seamless integration.

The Elo 2202L is backed by a comprehensive three-year warranty, providing peace of mind for your business investment. Contact us today to learn more about warranty coverage and support options available from Barcodes Inc.

The Elo 2202L comes with a Quick Install Guide, VGA and HDMI cables, Touch USB Cable (Part# E408193), Audio Cable, Power Brick (Part# E593661), NA and EU power cables, three tie wraps, and an EEI label. Everything you need for immediate setup and deployment is included.

The Elo E351600 Touchscreen is also known as ELO-E351600 or E351600.
