Elo E344056 Touchscreen Signage

Part Number: E344056
Model: 4363L
Add to My Shopping List Add to Compare
$1,850.35
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
43"
Viewable Screen Size
42.5"
Screen Mode
Full HD
Panel Technology
Thin Film Transistor (TFT)

Product Description:

  Touchscreens, Elo 4363L, 43" Wide LCD Open Frame, Full HD, VGA & HDMI 1.4, Projected Capacitive Touch 40-Touch with Palm Rejection & Touch Thru, Clear Anti-friction Glass, USB, Gray
Explore all Elo 4363L Touchscreens
Add to Quote
Elo E344056 Touchscreen Signage
Elo E344056 Touchscreen Signage
Elo E344056 Touchscreen Signage
Elo E344056 Touchscreen Signage
Elo E344056 Touchscreen Signage
Elo E344056 Touchscreen Signage Elo E344056 Touchscreen Signage Elo E344056 Touchscreen Signage Elo E344056 Touchscreen Signage Elo E344056 Touchscreen Signage
Full specifications (PDF)

Elo 4363L Touchscreen Model Overview

Elo's 4363L 42.5-inch LCD Open-Frame Touchscreen revolutionizes interactivity with its sleek design and robust performance. This commercial-grade monitor features a vivid full HD display and Touch Pro® PCAP technology, allowing for up to 40 simultaneous touches, ensuring an intuitive and engaging user experience. Ideal for use in retail, hospitality, and healthcare environments, the 4363L is built for 24/7 operation with exceptional durability, meeting UL60950 and IK07 standards for impact resistance. Designed to conserve energy with Energy Star 8.0 certification, this touch monitor pairs seamlessly with various enclosures and mounting orientations.


Key Features
  • 42.5-inch Full HD Open-Frame Display: Exceptional clarity and brightness.
  • Touch Pro® PCAP Technology: Supports palm rejection and through touch capability.
  • Multi-Touch Support: Up to 40 simultaneous touches for enhanced interactivity.
  • Energy Star 8.0 Certified: Designed for optimal energy efficiency.
  • Robust Durability: Exceeds impact resistance standards (UL60950 & IK07).

Specifications
  • Model: 4363L
  • Color: Black
  • Diagonal Size: 42.5" (1080 mm)
  • Native Resolution: 1920 x 1080 @ 60Hz
  • Brightness: LCD Panel 450 nits; TouchPro PCAP 387 nits
  • Touch Technology: TouchPro® PCAP - up to 40 touches
  • On-Screen Display: Accessible via switches
  • I/O Ports: HDMI x2, USB 2.0 Type B, RJ45, VGA
  • Operating Temperature: 0° C to 40° C
  • Weight: Unpackaged: 37.77 lbs; Packaged: 50.79 lbs
  • Warranty: 3 years standard; extended options available
Elo E344056 Touchscreen Signage Overview

The perfect touchscreen for any enclosure.

Elo's 4363L 43-inch full HD open-frame delivers a state-of-the-art slim form factor designed for easy integration into enclosures and kiosks. Whether for self-order and self-checkout kiosks or industrial controls, operating room control boards and wayfinding solutions, Elo's commercial-grade interactive displays offer the versatility to add touch to your solution.

Brilliant, interactiveTouchPro® PCAP display.

The 4363L offers anti-glare or anti-friction models with edge-to-edge glass and up to 40 simultaneous touches for an enhanced, tablet-like experience.

Captivate customers and employees with reliable,easy to use interactive solutions.

  • Payment and Ticketing
  • Operating Room Control Board
  • Point of Information
  • Self-Order/Self-Checkout
  • Automation/Industrial Controls
  • Wayfinding & Interactive Signage

Designed for easy integration.

Mount the 4363L touchscreen monitor in landscape, portrait and upward facing orientations, providing optimal flexibility for integrating in any counter, kiosk or cabinet design.

Get the viewing experience
you want to see.
Whether viewing straight on or at an angle, close-up or from a distance, Elo's touchscreen displays offer optimal clarity for the viewing experience.

Place your touchscreen behind an extra layer of protection.

For installations that require specific IP ratings or protection from vandalism and harsh environments, Elo's TouchPro PCAP displays offer touch thru capability. With touch thru technology, the display can be mounted behind a front layer of glass up to 6 mm or plastic up to 3 mm to create a fully enclosed kiosk.

Make your digital transformation faster,and more affordable.

Elo EssentialEdge™ for Android offers everything you need to build and operate interactive solutions for your business.

The Elo Backpack brings computing power that scales.

With the Elo Backpack you get a powerful, commercial-grade Android compute engine purpose-built to fit in compact spaces. Boasting a small footprint in both size and weight, the Elo Backpack can secure inside any kiosk with the built-in VESA mount. Scaling Elo's commercial Android platform across sizes and form factors has never been easier.

Full specifications (PDF)
Technical Information
Screen Size Class:
43"
Viewable Screen Size:
42.5"
Screen Mode:
Full HD
Panel Technology:
Thin Film Transistor (TFT)
Response Time:
8 ms
Response Time Details:
8 ms Typical
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
LED
HDCP Supported:
Yes
Features:
  • On-screen Display (OSD)
  • Ambient Light Sensor
Horizontal Frequency:
31.50 kHz to 80 kHz
Vertical Frequency:
47 Hz to 63 Hz
Video
Maximum Resolution:
1920 x 1080
Color Supported:
16.7 Million Colors
Native Contrast Ratio:
4,000:1
Brightness:
450 Nit
Touchscreen Information
Touchscreen Type:
Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
40
Interfaces/Ports
HDMI:
Yes
USB:
Yes
VGA:
Yes
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
400 x 400
Color Family:
Black
Product Color:
Black
Height:
23.1"
Width:
39.3"
Depth:
2.6"
Weight (Approximate):
37.77 lb
Miscellaneous
Energy Star:
Yes
Item Numbers
GTIN: 0843173126920
UPC: 843173126920
EAN: 0843173126920
UNSPSC: 43211903

Recommended Accessories

Category

  • Computer Components (2)
  • Digital Signage Display Accessories (1)
  • Touchscreen Accessories (1)

Recommended Accessories for Model: Elo E344056 Touchscreen Signage

Top Computer Components Purchased With Elo E344056

  • Elo E393359 Accessory
    Elo E393359 Accessory
    Compute Engine, Elo Backpack 4, Standard Model, USB/Ethernet/Bluetooth/Wi-Fi, HDMI, USB-C output, Micro-SD, GPIO, Qualcomm 660 4GB RAM, 64GB Storage, Android 10, Google Mobile Services, Black, Compatible with I-Series 4.
    Item on backorder — chat for lead time
    $643.61
    Add to Quote
  • Elo E393754 Accessory
    Elo E393754 Accessory
    Computer Components, Elo Backpack 4 Value, Android 10 with GMS, Rockchip 3399 Processor, 4GB RAM/32GB Flash, HDMI and USB-C out, Wi-Fi/Ethernet/Bluetooth 5.0, EloView Compatible, Black, Worldwide
    In Stock
    $655.64
    Add to Quote

Top Digital Signage Display Accessories Purchased With Elo E344056

Top Touchscreen Accessories Purchased With Elo E344056

Frequently Asked Questions

The Elo E344056 is a 43-inch full HD open-frame monitor designed for commercial signage applications. Its compact form factor allows it to fit into practically any enclosure while delivering crisp, high-resolution visuals ideal for retail, hospitality, healthcare, and industrial kiosks.

The Elo 4363L supports up to 40 simultaneous touches through its TouchPro PCAP technology, delivering a tablet-like interactive experience. This multi-touch capability makes it excellent for engaging customer interactions across various commercial environments.

Yes, the Elo 4363L features TouchPro technology with palm rejection and through-touch capabilities that work effectively even when wearing protective gloves, with sensitivity up to 6mm. This versatility makes it suitable for diverse work environments and use cases.

The Elo E344056 offers VGA and HDMI 1.4 video inputs along with USB connectivity, providing flexible integration options for various commercial systems and kiosks. These standard connections ensure broad compatibility with existing infrastructure.

Yes, the Elo 4363L is engineered for 24/7 usage and delivers high impact resistance by meeting UL60950 ball-drop and IK07 impact immunity standards. Its robust construction makes it ideal for demanding commercial environments requiring continuous operation.

The Elo 4363L carries Energy Star 8.0 certification, demonstrating excellent energy conservation that reduces power consumption and heat dissipation. This makes it an environmentally responsible choice for long-term signage and kiosk deployments.

The Elo E344056 Touchscreen Signage is also known as ELO-E344056 or E344056.
