The Elo 2494L 24-inch open frame touchscreen display delivers an industrial-grade solution that is cost-effective for OEMs and systems integrators requiring a reliable product for their customers. The Elo 2494L 23.8-inch open-frame touch display features a thin and compact state-of-the-art design, with energy-saving and low-heat LED panels. Available with IntelliTouch (SAW) or TouchPro (PCAP) touch technologies, the 2494L offers the versatility needed for commercial kiosk applications from industrial automation and gaming to self-service and retail. Featuring a brilliant wide viewing angle panel, Elo's open frames can be mounted in landscape, portrait, and face-up orientations providing optimal flexibility for integrating in any table, kiosk, or cabinet design. With proven Elo expertise and reliability built in, the industrial-grade displays provide outstanding image clarity and light transmissivity as well as stable, drift-free operation for accurate touch responses.
Elo E330019 Touchscreen Overview
The Elo 2494L 24-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions due to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch, with proven Elo expertise and reliability built in. The 2494L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Featuring a brilliant wide viewing angle panel, the open-frame touchscreen instantly grabs and holds the users' attention for kiosks, casino and amusement, retail self-service, and industrial automation environments.
Easily integrated.
The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected as well as backwards compatibility where we can make it possible to help minimize additional enclosure costs.
Touch ready.
Available with a choice of industry-leading touch technologies, in single-, dual- or multi-touch technology, including IntelliTouch® surface acoustic wave (SAW) with single- and dual-touch, IntelliTouch single-touch SAW with zero-bezel, and our latest multi-touch TouchPro™ PCAP two-glass solution (2GS) technology has a zero-bezel that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves.
Commercial-grade.
The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution with touch integrated from the start. Using our own touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life testing processes. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
Other features.
Viewing angle of 178° (h) x 178° (v), for sharp colors and graphics in both portrait and landscape modes
Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
10-touch TouchPro™ projected capacitive (PCAP) with two-touch Thru-glass capabilities
What touch technology options are available for the Elo 2494L touchscreen?
The Elo 2494L is available with two touch technology options: IntelliTouch (SAW) and TouchPro (PCAP). Both technologies deliver accurate, drift-free operation and stable touch responses, allowing you to select the solution that best fits your application requirements. Contact us today to discuss which touch technology is right for your deployment.
What video interfaces does the Elo E330019 support?
The Elo 2494L touchscreen features multiple video interface options including HDMI, VGA, and Display Port connectivity. This versatile connectivity ensures compatibility with a wide range of host systems and control platforms used in industrial and commercial environments.
Is the Elo 2494L suitable for kiosk and self-service applications?
Yes, the Elo 2494L is specifically designed for commercial kiosk applications including self-service, retail, and industrial automation environments. Its industrial-grade construction, brilliant wide viewing angle panel, and reliable drift-free touch response make it an excellent choice for customer-facing and automated systems that demand consistent performance.
Can the Elo 2494L be mounted in different orientations?
The Elo 2494L open-frame design supports flexible mounting in landscape, portrait, and face-up orientations, providing optimal flexibility for integrating into any table, kiosk, or cabinet design. This versatility allows system integrators and OEMs to optimize the display for their specific application layout.
What makes the Elo 2494L cost-effective for OEMs and systems integrators?
The Elo 2494L delivers industrial-grade reliability and performance at a cost-effective price point, making it ideal for OEMs and systems integrators who need to deliver dependable solutions to their customers. The display features energy-saving LED panels with low heat output, reducing operational costs while maintaining outstanding image clarity and light transmissivity.
What touch controller interfaces are supported by the Elo 2494L?
The Elo 2494L provides USB and RS-232 touch controller interfaces, enabling straightforward integration with a variety of host systems and control architectures. These standard interfaces ensure compatibility with legacy and modern systems alike, simplifying deployment in diverse environments.
The Elo E330019 Touchscreen is also known as
ELO-E330019
or E330019.
Full specifications (PDF)
