Elo E326942 Touchscreen

Part Number: E326942
Model: 1790L
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$697.00
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
17"
Viewable Screen Size
17"
Screen Mode
SXGA
Screen Surface
Anti-glare

Product Description:

  17" Touchscreen Monitor, L 179L Open-FrameLD, 5:4 Aspect Ratio, IntLiTouch SinL-Touch, 1280 x 1024, 16.7 mLion CLrs, 225 nits Brightness (typicL,LD BacLght, 1000:1 Contrast Ratio (typicL, HDMI, VGA & DisLy Port Video Interface, DuLSeriLUSB Touch ContrLer Interface, Anti-Lre, BezL L (Side Mount) Brackets, Lck, 3-Year Warranty, No Power Brick, WoLwide. Box InLdes HDMI CaL (Part# E538507), VGA CaL, RJ45 OSD Remote (Part# E483757), Touch USB CaL (Part# E546861), Quick InstL Guide, EEILbL Japan Lss-B TM Info Sheet, L (Side Mount) Brackets and w/ Screws (Part# E147211).
Explore all Elo 1790L Digital Signage Displays
Add to Quote
Elo E326942 Touchscreen
Elo E326942 Touchscreen
Elo E326942 Touchscreen
Elo E326942 Touchscreen
Elo E326942 Touchscreen
Elo E326942 Touchscreen
Elo E326942 Touchscreen Elo E326942 Touchscreen Elo E326942 Touchscreen Elo E326942 Touchscreen Elo E326942 Touchscreen

Full specifications (PDF)

Elo 1790L Digital Signage Display Model Overview

The Elo 1790L 17-inch Open-Frame Touch Display is expertly designed for various applications including kiosks, gaming, and industrial automation. Its slim profile and energy-efficient LED backlight not only reduce power consumption but also generate less heat. This compact touch display features advanced touch technologies for accurate touch responses and vibrant imagery. Protected against dust and water, it easily integrates into your systems, making it a reliable choice for system integrators and VARs.


Key Features
  • Choice of Elo touch technologies: Standard bezel (IntelliTouch SAW, SecureTouch anti-vandal SAW, AccuTouch five-wire resistive) and Zero-bezel (Projected Capacitive PCAP 2GS)
  • High quality energy-saving LED panel
  • 10 touch projected capacitive (PCAP) with Thru-glass capabilities
  • User-friendly video interfaces: Display Port and VGA

Specifications
  • Model: 1790L
  • Color: Black
  • Active Display Area: 337.9 x 270.3 mm / 13.3 x 10.6 inches
  • Diagonal: 17"
  • Native Resolution: 1280 x 1024 at 60Hz
  • Brightness (typical): 250 nits (LCD panel)
  • Weight: Unpackaged 7.9 lb (3.6 kg)
  • Warranty: 3 years standard
  • Agency Approvals: UL, FCC, CE, RoHS, and more
Elo E326942 Touchscreen Overview

Elo 1790L Open Frame Touchscreen Display

The Elo 1790L 17-inch open frame touchscreen display delivers an industrial-grade solution that is cost-effective for OEMs and systems integrators requiring a reliable product for their customers. Designed with reliability from the start, Elo's open frames deliver outstanding image clarity and light transmission with stable, drift-free operation for accurate touch responses. The 90-Series product line is available in a wide range of sizes, touch technologies and brightness, offering the versatility needed for commercial kiosk applications from self-service and gaming to industrial automation and healthcare.

More from the Manufacturer

Full specifications (PDF)
Technical Information
Screen Size Class:
17"
Viewable Screen Size:
17"
Screen Mode:
SXGA
Screen Surface:
Anti-glare
Panel Technology:
Thin Film Transistor (TFT)
Response Time:
5 ms
Aspect Ratio:
5:4
Horizontal Viewing Angle:
170°
Vertical Viewing Angle:
160°
Mount Type:
  • Front Mount
  • Rack-mountable
Backlight Technology:
LED
Features:
  • On-screen Display (OSD)
  • Anti-glare
Horizontal Frequency:
30 kHz to 82 kHz
Vertical Frequency:
50 Hz to 75 Hz
Curved Screen:
No
Video
Maximum Resolution:
1280 x 1024
Color Supported:
16.7 Million Colors
Contrast Ratio:
800:1
Native Contrast Ratio:
1,000:1
Brightness:
250 Nit
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
IntelliTouch Surface Wave
Interfaces/Ports
HDMI:
Yes
HDMI Version:
1.3
USB:
Yes
USB Standard:
USB 2.0
VGA:
Yes
DisplayPort:
Yes
DisplayPort Version:
1.1a
Serial Port:
Yes
Power Description
Operating Power Consumption:
17.80 W
Standby Power Consumption:
1.50 W
Off-Mode Power Consumption:
500 mW
Energy Consumption per Year:
30 kWh
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Product Color:
Black
Height:
12.1"
Width:
14.5"
Depth:
1.9"
Weight (Approximate):
7.94 lb
Miscellaneous
Package Contents:
  • 1790L 17" Open Frame Touchscreen (Rev B)
  • HDMI cable
  • VGA Cable
  • RJ45 OSD Remote
  • Touch USB Cable
  • Quick Install Guide
  • EEI Label
  • Japan Class-B TM info sheet
  • Side Mount Brackets and w/Screws
Certifications & Standards:
  • TÜV
    • Mean Time Between Failures (MTBF):
    5.7 Year
    Environmentally Friendly:
    Yes
    Environmental Certification:
    • RoHS
    • China RoHS
    • WEEE
    Country of Origin:
    China
    TAA Compliant:
    No
    Warranty
    Limited Warranty:
    3 Year
    Item Numbers
    GTIN: 0815335025822, 0818214085375, 4963273155937, 4963273156026
    UPC: 815335025822, 818213928420, 818214085375
    EAN: 0815335025822, 0818214085375, 4963273155937, 4963273156026
    UNSPSC: 43211903
