Elo E321195 Touchscreen

Part Number: E321195
Model: 1093L
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$451.00
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
10"
Viewable Screen Size
10.1"
Screen Mode
WXGA
Panel Technology
Thin Film Transistor (TFT)

Product Description:

  10.1" Touchscreen Monitor, Elo 1093L, Open-Frame LCD, 16:10 Aspect Ratio, Projected Capacitive 10-Touch, 1280 x 800 WXGA, 262k Colors, 315 nits Brightness (typical), LED Backlight, 800:1 Contrast Ratio (typical), HDMI, VGA & Display Port Video Interface, USB Touch Controller Interface, Clear, Bezel, Flush Mount, Black, 3-Year Warranty, No Power Brick, RoHS, China RoHS, WEEE, Worldwide. Box Includes HDMI Cable (Part# E538507), VGA Cable, Remote OSD (Part# E483757), Flush Mount Brackets w/ Screws (Part# E511656), Touch USB Cable (Part# E546861), Quick Install Guide, EEI Label, Japan Class-B TM Info Sheet. Optional Stylus Pen (Part# E066148) and Power Brick (Part# E005277) Not Included.
Explore all Elo 1093L Open-Frame Touchscreens
Add to Quote
Elo E321195 Touchscreen
Elo E321195 Touchscreen
Elo E321195 Touchscreen
Elo E321195 Touchscreen
Elo E321195 Touchscreen
Elo E321195 Touchscreen
Elo E321195 Touchscreen Elo E321195 Touchscreen Elo E321195 Touchscreen Elo E321195 Touchscreen Elo E321195 Touchscreen

Full specifications (PDF)

Elo 1093L Open-Frame Touchscreen Model Overview

Elo introduces the 1093L 10.1-inch open-frame LCD touchscreen, an ideal solution for various commercial applications. With its sleek design and energy-efficient LED backlight, this touchscreen saves power while ensuring exceptional image clarity and performance. The device boasts Elo's renowned TouchPro™ technology, providing accurate touch responses and 10-point multi-touch capabilities. Built for reliability, the 1093L is perfect for kiosks, retail self-service, and industrial automation, meeting the rigorous demands of commercial environments.
Key Features
  • 10.1-inch open-frame design for versatile installation.
  • TouchPro™ PCAP technology for enhanced clarity and touch durability.
  • 10 touch capability with thru-glass touch performance.
  • Sealed against dirt, dust and liquids for easy maintenance.
  • 3-Year Warranty for peace of mind.

Specifications
  • Model: 1093L
  • Active Display Area: 8.54" x 5.34" (216.96mm x 135.6mm)
  • Native Resolution: 1280 x 800 at 60 Hz
  • Brightness: LCD Panel: 350 nits; TouchPro PCAP: 315 nits
  • Response Time: 25msec
  • Viewing Angle: 85°/170°
  • Contrast Ratio: 800:1
  • Power Consumption: 6.1W (ON), 0.7W (SLEEP), 0.5W (OFF)
  • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
  • Weight: Unpackaged: 2.65 lbs / 1.2 kg
  • Mounting Options: 75mm VESA mount; Flush mount with included brackets
Elo E321195 Touchscreen Overview
The Elo 1093L 10.1-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions thanks to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact display is designed for touch, with proven Elo expertise and reliability built in. The 1093L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Instantly grabbing and holding users' attention, the open-frame touchscreen is perfect for kiosks, casino and amusement, retail self-service, and industrial automation environments.

Easily integrated.

The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected.

Touch ready.

This seamless, zero-bezel, 10-inch multi-touch display is available with our latest TouchPro™ PCAP two-glass solution (2GS) technology that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves.

Commercial-grade.

The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution, with touch integrated from the start. Using our touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life-testing processes. All our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.

Other features.
  • 10-touch TouchPro projected capacitive (PCAP) with two-touch thru-glass capabilities
  • Easy to integrate with flush mounting brackets on all 4 sides and rear 75 mm VESA mount
  • Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
  • Display Port and VGA video interfaces
Full specifications (PDF)
Technical Information
Screen Size Class:
10"
Viewable Screen Size:
10.1"
Screen Mode:
WXGA
Panel Technology:
Thin Film Transistor (TFT)
Response Time:
25 ms
Aspect Ratio:
16:10
Horizontal Viewing Angle:
170°
Vertical Viewing Angle:
170°
Mount Type:
Flush Mount
Backlight Technology:
LED
Features:
On-screen Display (OSD)
Horizontal Frequency:
30 kHz to 60 kHz
Vertical Frequency:
50 Hz to 75 Hz
Curved Screen:
No
Video
Maximum Resolution:
1280 x 800
Color Supported:
262,000 Colors
Contrast Ratio:
800:1
Brightness:
350 Nit
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
TouchPro Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
10
Interfaces/Ports
HDMI:
Yes
HDMI Version:
1.3
USB:
Yes
USB Standard:
USB 2.0
VGA:
Yes
DisplayPort:
Yes
DisplayPort Version:
1.1a
Power Description
Operating Power Consumption:
25 W
Standby Power Consumption:
700 mW
Off-Mode Power Consumption:
500 mW
Energy Consumption per Year:
10 kWh
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
75 x 75
Product Color:
Black
Height:
7"
Width:
10.1"
Depth:
1.5"
Weight (Approximate):
2.65 lb
Miscellaneous
Package Contents:
  • 1093L 10.1" Open Frame Touchscreen (RevB)
  • HDMI Cable
  • VGA Cable
  • RJ45 OSD Remote
  • Touch USB Cable
  • User Manual CD
  • Quick Install Guide
  • EEI Label
  • Japan Class-B TM info sheet
Certifications & Standards:
  • TÜV
    • Mean Time Between Failures (MTBF):
    5.7 Year
    Environmentally Friendly:
    Yes
    Environmental Certification:
    • RoHS
    • China RoHS
    • WEEE
    TAA Compliant:
    No
    Warranty
    Limited Warranty:
    3 Year
    Item Numbers
    GTIN: 0695975102219, 0815335025778, 0818213927782, 0818214082978
    UPC: 695975102219, 815335025778, 818213927782, 818214082978
    EAN: 0695975102219, 0815335025778, 0818213927782, 0818214082978
    UNSPSC: 43211903
