Elo E318746 Touchscreen

Part Number: E318746
Model: 1502L
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$705.00
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
16"
Viewable Screen Size
15.6"
Screen Mode
HD
Panel Technology
Thin Film Transistor (TFT)

Product Description:

  15.6" Touchscreen Monitor, Elo 1502L, Desktop LCD, 16:9 Aspect Ratio, Projected Capacitive 10-Touch, 1366 x 768/HD, 16.7 million Colors, 198 nits Brightness (typical), 400:1 Contrast Ratio (typical), mini-VGA and HDMI Video Interface, USB Touch Controller Interface, Anti-Glare, Zero-Bezel, Stand, Black, 3-Year Warranty, Speakers, Worldwide. Box Includes Quick Install Guide, HDMI Cable (Part# E538507), Power Brick (Part# E211174), 2x Cable Clamps, 2x Tie Wraps, Mini-VGA to VGA Cable (Part# E710549), USB Cable (Part# E210789), Audio Cable, 4x Screws.
Explore all Elo 1502L Touchscreens
Add to Quote
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen
Elo E318746 Touchscreen Elo E318746 Touchscreen Elo E318746 Touchscreen Elo E318746 Touchscreen Elo E318746 Touchscreen Elo E318746 Touchscreen Elo E318746 Touchscreen Elo E318746 Touchscreen Elo E318746 Touchscreen
Full specifications (PDF)

Elo 1502L Touchscreen Model Overview

The Elo 1502L Touchscreen Monitor is designed with the same seamless style that spans across the entire line up of 02-Series Monitors. With a compact form factor and flexible mounting options, Elo's 1502L is well-suited for POS, self-service, signage and customer-facing point of interaction. With a variety of peripherals, the monitor can be transformed to meet the demands of almost any blueprint. The Elo 1502L 15.6-inch touchscreen monitor delivers a professional-grade interactive solution featuring Elo's industry-leading TouchPro PCAP technology with edge-to-edge glass enabling up to 10 simultaneous touches. Backed by a three-year warranty, the feature rich monitor offers a sleek, low-profile, commercial-ready solution with dual built-in speakers and USB Type B or C (depending on the model), VGA and HDMI video connectors. Designed for commercial use, the 1502L simplifies business operations by delivering energy efficiency and versatile accessory options - from EMV and MSR payment devices to a barcode scanner and customer facing display.
Elo E318746 Touchscreen Overview
The Elo M-Series 1502L widescreen LED touch monitor is a modern and stylish interactive solution for customer engagement and employee effectiveness at the point of sale. The sleek wide aspect ratio touchscreen features full HD edge-to-edge glass with display area real estate to showcase engaging, memorable and rewarding content. An HD display model is available for transactional and other applications not requiring 1920x1080 resolution. For environments where space is scarce, the 1502L is an ideal POS terminal screen or stylish interactive information display. Built to withstand the rigors of continuous public use, the 1502L is well suited for high use retail venues. The sleek, thin look pairs well with any modern store environment.
Full specifications (PDF)
Technical Information
Screen Size Class:
16"
Viewable Screen Size:
15.6"
Screen Mode:
HD
Panel Technology:
Thin Film Transistor (TFT)
Response Time:
10 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
90°
Vertical Viewing Angle:
65°
Mount Type:
  • Wall Mountable
  • Pole Mount
Placement:
Tabletop
Backlight Technology:
LED
Features:
  • Anti-glare
  • On-screen Display (OSD)
  • Security Lock
  • Landscape/Portrait Viewable
  • Cable Lock Slot
Horizontal Frequency:
31.50 Hz to 60 Hz
Vertical Frequency:
60 Hz
Adjustable Stand Height:
Yes
Stand Adjustments:
Height
Curved Screen:
No
Number of OSD Languages:
8
Supported Graphics Resolutions:
  • 640 x 480 (VGA)
  • 720 x 576
  • 800 x 600 (SVGA)
  • 1024 x 768 (XGA)
  • 1280 x 1024 (SXGA)
  • 1280 x 720 (HD 720)
  • 1280 x 800 (WXGA)
  • 1280 x 960
  • 1360 x 768 (WXGA)
  • 1366 x 768
Video
Maximum Resolution:
1366 x 768
Color Supported:
262,000 Colors
Contrast Ratio:
600:1
Native Contrast Ratio:
700:1
Brightness:
220 Nit
Audio
Speakers:
Yes
Number of Speakers:
2
Speaker Output Power:
4 W
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
IntelliTouch Pro Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
10
Interfaces/Ports
HDMI:
Yes
USB:
Yes
VGA:
Yes
Number of HDMI Inputs:
1
Built-in Devices
Webcam:
No
Microphone:
No
Power Description
Operating Power Consumption:
10.20 W
Standby Power Consumption:
500 mW
Off-Mode Power Consumption:
200 mW
Energy Consumption per Year:
18 kWh
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Product Color:
Black
Height:
9.6"
Width:
15.2"
Depth:
1.3"
Weight (Approximate):
6.61 lb
Weight with Stand (Approximate):
6.72 lb
Miscellaneous
Mean Time Between Failures (MTBF):
5.7 Year
Item Numbers
GTIN: 0058293886078, 0834619009006
UPC: 058293886078, 834619009006
EAN: 0058293886078, 0834619009006
UNSPSC: 43211903
