Elo E265991 Touchscreen

Part Number: E265991

Model: 2270L

$469.14

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Screen Size Class

22"

Viewable Screen Size

21.5"

Screen Mode

Full HD

Panel Technology

Thin Film Transistor (TFT)

Product Description:

Touchscreen, Elo 2270L, 22-inch wide LCD Monitor, Full HD, Projected Capacitive 10-touch, USB Controller, Anti-glare, Zero-bezel, Collapsible Stand, VGA, DP and HDMI video interface, White, Worldwide

Explore all Elo 2270L Touchscreens

Add to Quote

Overview

Full specifications (PDF)

Elo 2270L Touchscreen Model Overview

Elo's 2270L 22-inch LCD Touchscreen Monitor combines sleek design with advanced functionality, making it an ideal choice for commercial environments. With a durable Touch Pro® PCAP touchscreen and options for clear or anti-glare surfaces, it ensures a stunning visual experience while minimizing eye strain with low blue light and flicker-free technology. Enjoy robust connectivity options including VGA, HDMI, and DisplayPort, along with built-in dual speakers for multimedia applications. Its compact and minimalist aesthetics seamlessly complement any setting, from POS systems to interactive digital signage. Backed by a three-year warranty, the 2270L is your reliable partner for interactive engagement.
Key features:

Durable Design: IK07 impact protection with scratch-resistant glass.
Energy Efficient: Energy Star 8.0 certified for lower power consumption.
Flexible Stand: Adjustable from 20° to 70° for optimal viewing angles.
High-Resolution Display: Full HD 1920 x 1080 resolution.
Wide Connectivity: Multiple input options including VGA, and DisplayPort.

Specifications:

Color: Black
Diagonal Size: 21.5" (546.1 mm)
Touch Technology: TouchPro PCAP, up to 10 touches
Brightness: 250 nits (Panel), 225 nits (with TouchPro)
Contrast Ratio: 1000:1
Viewing Angle: 178° (horizontal and vertical)
Dimensions: 19.87" x 11.91" x 1.63" / 504.7 mm x 302.4 mm x 41.3 mm
Weight: 9.04 lbs / 4.1 kg
Warranty: 3 years standard

Elo E265991 Touchscreen Overview

The bezel just got smaller.

The 2270L 22" touchscreen offers up to a 70% reduction in the bezel compared to similar models.

Minimalistic design to fit any space.

From 20 degrees to 70 degrees, angle the display where you want it.

Place it on a desktop, mount it on a wall or configure the 2270L to fit your space with VESA compatibility.

Built-in

Speakers and integrated IO.

Durable, energy efficient touchscreen.

Scratch-resistant glass surface.
IK07 impact resistant.
ES8.0 certified for greater energy efficiency.

Increase viewing comfort with low blue light and flicker free features.

Navigate the OSD directly on the touchscreen.

We have made it easier to manage your On-Screen Display (OSD) controls - Now you can use the touchscreen or the controls you are used to on the rear side of the monitor.

Detailed Specs

Full specifications (PDF)

Technical Information

Screen Size Class:

22"

Viewable Screen Size:

21.5"

Screen Mode:

Full HD

Panel Technology:

Thin Film Transistor (TFT)

Response Time:

14 ms

Response Time Details:

14 ms Typical

Aspect Ratio:

16:9

Horizontal Viewing Angle:

178°

Vertical Viewing Angle:

178°

Mount Type:

Wall Mountable

Placement:

Tabletop

Backlight Technology:

LED

Features:

Scratch Resistant
ComfortView
Low Blue Light
Flicker-free
On-screen Display (OSD)
Anti-glare
Power Switch
LED Indicator
OSD/Power Lock

Horizontal Frequency:

30 kHz to 82 kHz

Vertical Frequency:

50 Hz to 75 Hz

Impact Protection (IK) Rating:

IK07

Video

Maximum Resolution:

1920 x 1080

Color Supported:

16.7 Million Colors

Native Contrast Ratio:

1,000:1

Brightness:

250 Nit

Audio

Speakers:

Yes

Touchscreen Information

Touchscreen Type:

TouchPro Projected Capacitive

Multi-touch Screen:

Yes

Number of Simultaneous Touchpoints:

Interfaces/Ports

HDMI:

Yes

USB:

Yes

VGA:

Yes

DisplayPort:

Yes

Number of USB Ports:

Power Description

Frequency:

50 Hz
60 Hz

Physical Characteristics

VESA Mount Compatible:

Yes

VESA Mount Standard:

100 x 100

Color Family:

White

Product Color:

White

Height:

11.9"

Width:

19.9"

Depth:

1.6"

Weight (Approximate):

9.04 lb

Miscellaneous

Energy Star:

Yes

Item Numbers

GTIN: 0843173149769

UPC: 843173149769

EAN: 0843173149769

UNSPSC: 43211903

Reviews

FAQs

Questions? Get help from
a POS Expert!

The Elo E265991 Touchscreen is also known as ELO-E265991 or E265991.
