Elo E103538 Touchscreen Signage

Part Number: E103538
Model: 5054L
Add to My Shopping List Add to Compare
$2,821.57
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
50"
Viewable Screen Size
50"
Screen Mode
4K UHD
Response Time
9.50 ms

Product Description:

  Touchscreen Signage, Elo 5054L, 50-inch wide LCD Monitor, 4K UHD, HDMI 2.0 & DisplayPort 1.4, Projected Capacitive 40-Touch with Palm Rejection & Touch Thru, Clear Anti-friction Glass, USB-C, Black
Explore all Elo 5054L Touchscreen Signages
Add to Quote
Elo E103538 Touchscreen Signage
Elo E103538 Touchscreen Signage
Elo E103538 Touchscreen Signage
Elo E103538 Touchscreen Signage
Elo E103538 Touchscreen Signage
Elo E103538 Touchscreen Signage
Elo E103538 Touchscreen Signage
Elo E103538 Touchscreen Signage Elo E103538 Touchscreen Signage Elo E103538 Touchscreen Signage Elo E103538 Touchscreen Signage Elo E103538 Touchscreen Signage Elo E103538 Touchscreen Signage Elo E103538 Touchscreen Signage
Full specifications (PDF)

Elo 5054L Touchscreen Signage Model Overview

The Elo 5054L 50" Touchscreen Signage delivers an exceptional interactive experience, making it perfect for retail environments, transportation hubs, and public displays. With its sleek black bezel, this 50" active matrix TFT LCD touchscreen boasts a stunning 3840 x 2160 native resolution and a wide viewing angle of ±89°. Enhanced with TouchPro® PCAP technology, it supports up to 40 simultaneous touches, ensuring responsive and intuitive interactions. Additional features, such as built-in IoT control and robust connectivity options, create a versatile display solution to meet various digital signage needs.


Key Features
  • Native Resolution: 3840 x 2160 @ 60 Hz
  • Touch Technology: TouchPro® PCAP and Infrared
  • Brightness: 500 nits typical
  • Wide Viewing Angle: ±89° horizontal and vertical
  • Integrated IoT Control: EloView supported
  • Versatile Mounting Options: VESA 400 x 400mm

Specifications
  • Display Size: 50" / 1270 mm diagonal
  • Active Display Area: 43.14" x 24.27" / 1095.8 mm x 616.4 mm
  • Aspect Ratio: 16:9
  • Contrast Ratio: 4000:1
  • Response Time: 9.5 msec
  • Operating Temperature: 0 °C to 40 °C
  • Weight: 56.79 lbs / 24.23 kg (unpackaged)
  • Warranty: 3 years standard
  • Power Consumption: 99 W ON, 1.8 W SLEEP, 0.28 W OFF
  • Shipping Dimensions: 51.57" x 37" x 7.36"
Elo E103538 Touchscreen Signage Overview

5054l 50 Inch Interactive Touch Monitor

Enhance your applications with the Elo 5054L 50" touchscreen monitor, bringing interactivity to any environment. With support for up to 40 simultaneous touches, lightning-fast response time, and anti-friction glass to minimize heat, the Elo 5054L puts the user experience first. And by combining the touch display with the Elo Backpack or a Brightsign Player, you can effortlessly transform this display into a versatile,life-sized 50" tablet.

Remotely manage devices with EloView.

With the additional built-in IoT control, you can easily manage your device settings with EloView or Crestron as well as your preferred MDM solution via APIs.

Touch-Thru-Glass functionality with PCAP

Elo's TouchPro® PCAP interactive displays are touch-sensitive and can be mounted behind a mirror, counter, or in a fully enclosed kiosk for added robustness,durability, and aesthetics.

Versatile mounting options for commercial interactive displays.

Wall, table or kiosk? Our interactive displays for commercial use give you flexibility. Thanks to the numerous mounting options, they can be mounted in landscape or portrait format or even lying flat,so our touchscreens can be used in a wide range of installation situations.

Designed to meet the demands of commercial environments.

Designed for 24/7 use in high-traffic environments and meeting UL-60950 and IK-07 requirements, Elo's 5054L delivers the reliability and durability businesses need in the most demanding conditions. With extended product lifecycles and global certifications, you can be confident in the 5054L's long-term performance and suitability for various international markets.

Full specifications (PDF)
Technical Information
Screen Size Class:
50"
Viewable Screen Size:
50"
Screen Mode:
4K UHD
Response Time:
9.50 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Mount Type:
Wall Mountable
Backlight Technology:
LED
HDCP Supported:
Yes
Features:
  • On-screen Display (OSD)
  • Ambient Light Sensor
Horizontal Frequency:
30 kHz to 135 kHz
Vertical Frequency:
24 Hz to 64 Hz
Stand Adjustments:
Tilt
Bezel Color:
Black
Operation Hours:
24 Hours/7 Days
Impact Protection (IK) Rating:
IK07
Active Display Area (H x V):
43.10" x 24.20"
Video
Maximum Resolution:
3840 x 2160
Color Supported:
1.07 Billion Colors
Native Contrast Ratio:
4,000:1
Brightness:
430 Nit
Audio
Speakers:
Yes
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
40
Network & Communication
Connectivity Technology:
Wired
Interfaces/Ports
HDMI:
Yes
USB:
Yes
DisplayPort:
Yes
USB Type-C:
Yes
Total Number of HDMI Ports:
2
Number of HDMI 2.0 Ports:
2
Environmental Conditions
Operating Temperature Range:
32°F (0°C) to 104°F (40°C)
Operating Humidity Range:
20% to 80% (Non-condensing)
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Frequency:
  • 50 Hz
  • 60 Hz
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
400 x 400
Color Family:
Black
Product Color:
Black
Height:
26.8"
Width:
45.7"
Depth:
2.1"
Weight (Approximate):
53.42 lb
Miscellaneous
Energy Star:
Yes
Application/Usage:
Commercial
Item Numbers
GTIN: 0843173156064
UPC: 843173156064
EAN: 0843173156064
UNSPSC: 43211903
