Elo E016808 Touchscreen

Elo 1723L - 17" Touchscreen Monitor, Elo 1723L, Desktop LCD, 5:4 Aspect Ratio, Projected Capacitive 10-Touch, 1280 x 1024 SXGA, 16.7 million Colors, 215 nits Brightness (typical), LED Backlight, 1000:1 Contrast Ratio (typical), VGA & DVI Video Interface, USB Touch Controller Interface, Anti-Glare, Zero-Bezel, Stand, White, 3-Year Warranty, Speakers, RoHS, China RoHS, WEEE, Worldwide. Box Includes Quick Install Guide, Japan Class-B TM Info Sheet, User Manual CD, 50W Power Brick, Power Cable (Part# E378229), IEC 60320-C13 to NA/EU Plug, DVI-D Cable, VGA Cable (DB-15 Male to DB-15 Male), USB Cable (Type A Plug to Type B Plug), Audio Cable, Stand Base Assembly (Part# E574298), Filler Plate (Part# E000451).
  • The IntelliTouch Pro Projected Capacitive touchscreen technology offers two essential advantages, not only can you touch the panel with your bare finger, but you can also actuate it with surgical gloves or slender cotton gloves on
  • The SXGA touchscreen highlights SXGA display with the resolution of up to 1280 x 1024 pixels
  • The 800:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
  • LED backlight technology provides for industry-leading low power consumption and less hazardous materials
  • Enjoy crisp content and energetic hues with the 250 Nit brightness
  • VESA mount compatibility allows you to mount the touch screen on a wall or with a stand depending on your specific needs
Read More

Need a different version? See all Elo 1723L Touchscreens

$965.00
Add to Quote
Add to My Shopping List Add to Compare
Elo E016808 Touchscreen
Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen
Elo E016808 Touchscreen

Full specifications (PDF)
Elo 1723L Touchscreen Model Overview
The Elo Touch Solutions 1723L 17-inch touchmonitor is well-suited to meet the durability and aesthetic requirements for a variety of high traffic retail and hospitality interactive solutions. Retail peripheral accessories include an encryptable MSR, NFC/RFID for contactless payments, webcam, and rear-facing display bracket. The edge to edge flat glass style of the 1723L brings a sleek, modern feel to any application. It is available in two touchscreen technologies, IntelliTouch Zero-Bezel surface acoustic wave, and IntelliTouch Pro projected capacitive with anti-glare surface coating, supporting 10-touch interaction right out of the box.
Elo E016808 Touchscreen Overview

The Elo Touch Solutions 1723L 17-inch touchmonitor is well-suited to meet the durability and aesthetic requirements for a variety of high traffic retail and hospitality interactive solutions. Retail peripheral accessories include an encryptable MSR, NFC/RFID for contactless payments, webcam, and rear-facing display bracket.

The edge to edge flat glass style of the 1723L brings a sleek, modern feel to any application. It is available in two touchscreen technologies, IntelliTouch Zero-Bezel surface acoustic wave, and IntelliTouch Pro projected capacitive with anti-glare surface coating, supporting 10-touch interaction right out of the box.

Both touch technologies provide a stable "drift-free" operation with outstanding image clarity, resolution and light transmission - for an accurate touch response and vivid images.

The 1723L has been "designed for touch" from the ground up, with such features as a spill-resistant sealing, adjustable height stand with tilting functionality, VESA mounting option, connectivity incorporated within the monitor (reducing the number of power bricks), and communication cables and side controls with lockout capability.

Full specifications (PDF)
Technical Information
Screen Size Class:
17"
Viewable Screen Size:
17"
Screen Mode:
SXGA
Response Time:
30 ms
Aspect Ratio:
5:4
Mount Type:
Wall Mountable
Backlight Technology:
LED
Video
Maximum Resolution:
1280 x 1024
Color Supported:
16.7 Million Colors
Contrast Ratio:
800:1
Brightness:
250 Nit
Audio
Speakers:
Yes
Touchscreen Information
Touchscreen Type:
IntelliTouch Pro Projected Capacitive
Multi-touch Screen:
Yes
Interfaces/Ports
DVI:
Yes
USB:
Yes
VGA:
Yes
Power Description
Operating Power Consumption:
22 W
Physical Characteristics
VESA Mount Compatible:
Yes
Product Color:
White
Height with Stand:
8.24"
Width with Stand:
15.42"
Depth with Stand:
14.20"
Weight (Approximate):
7.86 lb
Weight with Stand (Approximate):
25.35 lb
Miscellaneous
Package Contents:
  • 1723L Multifunction 17-inch Desktop Touchmonitor
  • Touch/Video/Accessory Cables
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • China RoHS
  • WEEE
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0834619007361, 4058829163433
UPC: 834619007361
EAN: 0834619007361, 4058829163433
UNSPSC: 43211903
Questions? Get help from
a POS Expert!

What is your POS application?

The Elo E016808 Touchscreen is also known as ELO-E016808 or E016808.
