Eaton T100H-1800 Products

Part Number: T100H-1800
Model: Parts
Add to My Shopping List Add to Compare
CA$1,553.42
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Protection Type
AC NoiseOverloadEMI / RFI
Plug/Connector Type
NEMA L5-20P
Receptacle Type
NEMA 5-20R
Receptacles Detail
2 x NEMA 5-20R

Product Description:

  Eaton Power-Suppress 100 T100H-1800 Line Conditioner - 110V AC, 220V AC
Explore all Eaton Parts Products
Add to Quote
Eaton T100H-1800 Products
Eaton T100H-1800 Products
Technical Information
Protection Type:
  • AC Noise
  • Overload
  • EMI / RFI
Plug/Connector Type:
NEMA L5-20P
Receptacle Type:
NEMA 5-20R
Receptacles Detail:
2 x NEMA 5-20R
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Input Voltage Range:
120 V AC - 240 V AC
Maximum Frequency:
60 Hz
Physical Characteristics
Height:
10.3"
Width:
11.1"
Depth:
17"
Miscellaneous
Additional Information:
  • 1.8kVA
  • Output: 1800VA
  • Common-mode: noise 140dB @ 100kHz
  • Normal-mode: noise 65dB @ 100kHz
  • Dielectric Strength: 600% for 1 cycle 300% for 30 seconds
  • Frequency: 60 Hz ±5%
  • Impedance: 2 - 5% typical
  • Efficiency: 93 - 97% typical
  • Input voltage range: ±10% of nominal rated voltage
  • Load regulation: 2 - 5% or less from no load to full load at unity power factor
  • Harmonic distortion: Adds less than 1% THD, under linear loading
  • Coil insulation: 200ºC
  • Temperature Rise: 115ºC max rise above a 40ºC ambient, depending on model
Certifications & Standards:

Safety Agency:

  • UL 1012
  • UL 1449
  • cUL listed
  • ANSI/IEEE C57.12.91 Meets FCC Category A
  • IEEE C62.41Category A3
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0743172021106
UPC: 743172021106
EAN: 0743172021106
UNSPSC: 39121020
The Eaton T100H-1800 Products is also known as POW-T100H1800
