Technical Information
Plug/Connector Type:
Hardwired
Receptacle Type:
- NEMA L14-30R
- NEMA L6-30R
- NEMA 5-20R
Receptacle Detail:
- 3 x NEMA L14-30R
- 3 x NEMA L6-30R
- 12 x NEMA 5-20R
Power Description
Load Capacity (VA):
12 kVA
Management
Alarm:
- Low Battery
- High Battery
- Low AC Output
- High AC Output
- High AC Input
- Output Overload
- Overload Shutdown
- High Heatsink Temperature
- Emergency Power Off
- Module Failure
- Excessive Transfer
- Precharge Failure
- Incompatible Module
- Fan Failure
- Low Runtime
- Check Memory
- Check Battery Open Cell
- Check Battery Weak Battery
- Low Redundancy Insufficient Battery
- Low Redundancy Insufficient Module
- Check Battery
- Phase Error
Controls/Indicators
Interfaces/Ports
Modular Slots:
2 x Communications Slot
Battery Information
Battery Characteristics:
Maintenance-free
Battery Chemistry:
Lead Acid
Backup/Run Time (Full Load):
8 Minute
Backup/Run Time (Half Load):
24 Minute
Typical Battery Recharge Time:
4 Hour
Environmental Conditions
Maximum Operating Temperature:
104°F (40°C)
Sound Emission (A-Weighted):
50 dB(A)
Miscellaneous
Additional Information:
- Eliminates single point-of-failure with N+X power and logic redundancy
- Grows with changing IT environments by incorporating scalable design of 3 kVA power modules and batteries
Certifications & Standards:
- UL
- CUL
- FCC class A
- IEEE/ANSI C62.41
Country of Origin:
United States
Warranty
Item Numbers
GTIN:
0000003336380, 0743172066169
UPC:
000003336380, 743172066169
EAN:
0000003336380, 0743172066169
UNSPSC:
39121011
