DT Research 515T-E7B-H3G0 POS Touch Terminal

Part Number: 515T-E7B-H3G0

Model: DT515T

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Number of Processors Supported

Number of Processors Installed

Processor Manufacturer

Intel

Processor Type

Atom

Product Description:

DT Research DT500T DT515T All-in-One Computer - Intel Atom Dual-core (2 Core) 1.86 GHz - 4 GB RAM - 320 GB HDD - 15" XGA 1024 x 768 - Desktop - Black - Windows Embedded Standard 7 - Intel HD Graphics

Explore all DT Research DT515T Touchscreens

Add to Quote

DT Research 515T-E7B-H3G0 POS Touch Terminal

Overview

Full specifications (PDF)

DT Research DT515T Touchscreen Model Overview

The DT515T series digital terminals integrate vivid displays with Intel Atom dual core platforms in slim, mountable packages. These LCD-integrated computers feature the integration of bright 15" displays, respectively, over energy efficient Intel Atom dual core processor-powered thin client platforms. With optional IR touch screens, internal wireless communication, and magnetic stripe readers, the full-featured, space-saving systems accommodate a range of accessories and peripherals to support a wide variety of vertical applications.

Detailed Specs

Full specifications (PDF)

Processor

Number of Processors Supported:

Number of Processors Installed:

Processor Manufacturer:

Intel

Processor Type:

Atom

Processor Core:

Dual-core (2 Core)

Processor Speed:

1.86 GHz

Cache:

1 MB

Memory

Standard Memory:

4 GB

Memory Card Reader:

Yes

Storage

Total Hard Drive Capacity:

320 GB

Hard Drive Interface:

Serial ATA

Controllers

Controller Type:

Serial ATA

Display & Graphics

Screen Size:

15"

Display Screen Type:

Active Matrix TFT Color LCD

Screen Mode:

XGA

Screen Resolution:

1024 x 768

Aspect Ratio:

4:3

Graphics Controller Manufacturer:

Intel

Graphics Controller Model:

HD Graphics

Graphics Memory Accessibility:

Shared

Network & Communication

Ethernet Technology:

Gigabit Ethernet

Interfaces/Ports

Total Number of USB Ports:

Number of USB 2.0 Ports:

Network (RJ-45):

Yes

Audio Line In:

Yes

Audio Line Out:

Yes

Software

Operating System Platform:

Windows

Operating System:

Windows Embedded Standard 7

Power Description

Input Voltage:

120 V AC
230 V AC

Physical Characteristics

Color:

Black

Form Factor:

Desktop

Height:

10.9"

Width:

13.9"

Depth:

2.5"

Weight (Approximate):

10.58 lb

Miscellaneous

Package Contents:

DT515T All-in-One Computer
1 x Desktop Stand
AC-DC Power Adapter
Power Cord
Documentation

Certifications & Standards:

IP65
FCC Class B
CE
C-Tick

Environmentally Friendly:

Yes

Environmental Certification:

RoHS

Warranty

Limited Warranty:

1 Year

Item Numbers

UNSPSC: 43211507
