DITEK DTK-SL95B Products

DITEK - DITEK DTK-SL95B Snap-Lite Surge Suppressor - 95 V AC Input - 95 V AC Output - Telecommunication

Need a different version? See all DITEK Parts Accessories

$26.28
Add to Quote
Add to My Shopping List Add to Compare
DITEK DTK-SL95B Products
DITEK DTK-SL95B Products
DITEK DTK-SL95B Products
DITEK Parts Accessory Model Overview
Products and parts from DITEK.
DITEK DTK-SL95B Products Overview

The DITEK Snap-Lite quick-connect line protector is designed specifically for Voice/Data professional. The Snap-Lite provides both voltage and current limiting in addition to surge protection. The unique Multi-function diagnostic LED shows protection status, line continuity and line usage. Available in four different voltages, there is a Snap-Lite for virtually and analog 66 block application.

Technical Information
Dataline Protection:
Telecommunication
Power Description
Input Voltage:
95 V AC
Output Voltage:
95 V AC
Maximum Line Current:
2 A
Maximum Surge Current:
4 kA
Physical Characteristics
Height:
1.6"
Width:
3.2"
Depth:
0.4"
Weight (Approximate):
0.50 oz
Miscellaneous
Additional Information:
  • Quick connect module - no bridge clips required!
  • Each Snap-Lite protects one pair
  • Self-resetting fusing
  • Field-replaceable
  • Clamping Voltage: 150V
Warranty
Limited Warranty:
10 Year
Item Numbers
GTIN: 0782980509772
UPC: 782980509772
EAN: 0782980509772
UNSPSC: 39121610
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The DITEK DTK-SL95B Products is also known as DTK-SL95B
