Digi 70001851 Console & Device Servers

Part Number: 70001851
Model: One SP Device Server
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$306.41
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Network (RJ-45)
Yes
Serial Port
Yes
Number of Network (RJ-45) Ports
1
Number of Serial Ports
1

Product Description:

  One SP Device Server, RS-232/422/485 switch selectable ports, DB-9M serial connector, Baud rates up to 230 Kbps, 10/100Base-T Ethernet support, Patented RealPort technology for COM and TTY ports, LED status for link and power, Minimum Order of 10.
Explore all Digi One SP Device Server Data Networkings
Add to Quote
Digi 70001851 Console & Device Servers
Digi 70001851 Console & Device Servers
Digi 70001851 Console & Device Servers Digi 70001851 Console & Device Servers
Full specifications (PDF)

Digi One SP Device Server Data Networking Model Overview

The Digi One SP device server is the perfect solution for standard serial-to-Ethernet connectivity, ideal for applications that require reliable and straightforward data communications. Its compact design ensures cost-effective performance, while enabling easy integration of devices equipped with serial ports into an Ethernet network. The Digi One SP is designed for various applications, including serial tunneling, and allows for seamless operation of legacy software over a network, eliminating the need for lengthy serial cables.
Key Features
  • Easy configuration using installation CD.
  • Patented Digi RealPortⓇ technology for COM and TTY port management.
  • Broad device connectivity with TCP/UDP Socket Services.
  • Auto-connect serial devices to networked servers using multiple protocols.
  • Switch selectable EIA-232/422/485 for versatile interfacing.
  • Modem emulation supports devices designed for modem communications.

Specifications
  • Serial Ports: EIA-232/422/485 switch selectable
  • Connector Type: DB-9M serial connector
  • Baud Rate: Up to 230 Kbps
  • Ethernet: 10/100Base-T support
  • IP Configuration: DHCP/RARP/ARP-Ping
  • Power Supply: 110/240 VAC power supply (12Vdc @ 0.4 Amps max)
  • Operating Temperature: 10°C to 45°C (50°F to 131°F)
  • Weight: 2.29 oz (65 g)
  • Dimensions: 3.7 in x 1.72 in x 0.93 in
Digi 70001851 Console & Device Servers Overview
The Digi One SP device server easily allows any device with a serial port to connect to the Ethernet. The compact design of the Digi One SP delivers cost-effective performance and capability in one of the smallest form factors available.
Full specifications (PDF)
Interfaces/Ports
Network (RJ-45):
Yes
Serial Port:
Yes
Number of Network (RJ-45) Ports:
1
Number of Serial Ports:
1
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Input Current:
400 mA
Physical Characteristics
Form Factor:
Desktop
Height:
3.7"
Width:
1.7"
Depth:
0.9"
Weight (Approximate):
2.24 oz
Miscellaneous
Additional Information:
  • Easy configuration using install CD
  • Patented Digi RealPort® technology for COM or TTY port control and management
  • TCP/UDP Socket Services for broad device connectivity and application use
  • Auto-connect the serial device to networked server using raw, Telnet, Rlogin
  • Reverse Telnet for easy access of serial devices from network
  • Easy configuration through web interface (HTTP)
  • Switch selectable EIA-232/422/485 for simple interfacing to any type of serial device
  • Full modem and hardware flow control
  • Input power supports 9-30Vdc @ .5Amps max
Compatibility:
OPERATING SYSTEMS:
  • RealPort drivers for COM/TTY support:
    - AIX
    - HP-UX
    - Linux
    - Microsoft® Windows 98/98SE
    - Microsoft® Windows ME
    - Microsoft® Windows XP®
    - Microsoft Windows 2000®
    - Microsoft Windows NT®
    - SCO® OpenServer
    - SCO UnixWare
    - Solaris (Intel)
    - Solaris (SPARC)
Certifications & Standards:
  • FCC Part 15, A
  • CE
  • EN5024-1
  • EN 50082-1
  • UL 1950
  • CSA 22.2 No 950
Warranty
Limited Warranty:
5 Year
Additional Warranty Information:
You can purchase with confidence knowing that Digi is here to support you with expert technical support
Item Numbers
GTIN: 0663072926076, 0724627023777, 0993248590696, 7426101891874
UPC: 663072926076, 724627023777, 993248590696
EAN: 0663072926076, 0724627023777, 0993248590696, 7426101891874
UNSPSC: 43222625
