What wireless standards and frequencies does the HPE Aruba 670 Series support?
The HPE Aruba 670 Series features Wi-Fi 6E tri-radio technology operating concurrently on 2.4 GHz, 5 GHz, and 6 GHz bands with 2×2:2 MIMO configuration. This delivers up to 3.9 Gbps aggregate throughput, with the 6 GHz band reaching 2.4 Gbps on HE160 channels, the 5 GHz band delivering 1.2 Gbps on HE80 channels, and the 2.4 GHz band providing 287 Mbps on HE40 channels. The tri-radio design enables simultaneous support for high-density client access, video analytics, and point-of-sale applications.
Is the HPE Aruba 670 Series suitable for harsh outdoor environments?
Yes, the 670 Series is engineered for mission-critical outdoor deployments with an IP66/67 ruggedized housing that withstands aggressive wash-down, salt-laden air, and extreme temperatures ranging from –40 °C to +70 °C. The enclosure is salt spray and high-wind rated, and includes built-in surge protection and EMI shielding to ensure reliable operation in demanding conditions. We offer these access points as ideal solutions for public safety communications, logistics yards, and outdoor venue deployments.
What IoT and location services are integrated into the 670 Series?
The 670 Series includes onboard high-power Bluetooth 5 and IEEE 802.15.4/Zigbee radios that create a consolidated IoT backbone for large-scale device connectivity. It also features a built-in GNSS L1 receiver that enables precise location-aware services, auto-discovery, and mapping capabilities. These integrated radios eliminate the need for separate IoT infrastructure and simplify network deployment.
What power and connectivity options does the HPE Aruba 670 Series provide?
The 670 Series supports multiple connectivity and power options including a 2.5 GbE PoE-PD uplink for powered network connection, a 1 GbE SFP uplink for fiber connectivity, and dual USB host ports for failover or edge compute integration. Maximum power draw is 45.5 W PoE-PD (Class 6), making it compatible with enterprise-grade PoE infrastructure. These flexible connectivity options enable seamless integration into existing network architectures.
Are there hazardous location variants available for the 670 Series?
Yes, the HPE Aruba 670 Series includes HazLoc EX variants certified for Class 1 Division 2 and Zone 2 installations, making them suitable for facilities with explosive atmospheres or hazardous material handling environments. These variants maintain the same Wi-Fi 6E tri-radio performance and rugged construction while meeting regulatory compliance requirements. Contact us today to discuss HazLoc variant availability and specifications for your specific application.
What mounting and warranty options are available for the 670 Series?
The HPE Aruba 670 Series comes with a limited lifetime hardware warranty and features advanced replaceable modules for extended serviceability. Mounting options include pole, arm, and bracket kits available separately to accommodate various outdoor installation scenarios such as rooftops, utility poles, and wall surfaces. Visit barcodesinc.com to explore mounting accessories and warranty details for your deployment.
