What wireless standards and bands does the HPE Aruba JZ345A support?
The HPE Aruba JZ345A is a Wi-Fi 6E access point that operates across three bands: 2.4 GHz, 5 GHz, and 6 GHz, using dual 2×2:2 radios for flexible deployment. This tri-band configuration delivers peak data rates of 2.4 Gbps on 6 GHz, 1.2 Gbps on 5 GHz, and 287 Mbps on 2.4 GHz, with a combined aggregate throughput of 3.6 Gbps. We offer this model as part of our comprehensive wireless access point portfolio for hospitality and high-density environments.
How is the HPE Aruba JZ345A powered, and what are its power consumption specs?
The JZ345A supports dual power options: IEEE 802.3at/802.3bt PoE (Power over Ethernet) or 12 V DC external power supply. Maximum power consumption is 14.9 W when using DC power and 27.5 W when drawing power via PoE-PSE, making it efficient for extended deployments. The 2.5 GbE PoE-PD uplink and four 1 GbE PoE-PSE downstream ports simplify network and power distribution across your infrastructure.
What connectivity and edge computing features does this access point offer?
Beyond wireless connectivity, the JZ345A includes a 2.5 GbE PoE-PD uplink for backbone connection, four 1 GbE PoE-PSE ports for downstream IoT and security devices, and a USB 2.0 host port for on-premises compute or security appliances. Built-in multi-GNSS L1 positioning enables asset tracking without additional hardware, making it ideal for hospitality venues and logistics-heavy environments. Contact us today to discuss edge deployment scenarios for your facility.
Is the HPE Aruba JZ345A suitable for high-density hospitality environments?
Yes, the JZ345A is specifically designed for high-density hospitality settings where guests require seamless video conferencing, streaming, and IoT connectivity. Its 3.6 Gbps combined throughput and tri-band operation ensure robust performance across multiple simultaneous users and bandwidth-intensive applications. We offer this model as a proven solution for hotels, resorts, and conference centers requiring enterprise-grade wireless infrastructure.
What security and thermal protection features are built into the JZ345A?
The JZ345A includes TPM 2.0 (Trusted Platform Module) hardware security for encrypted key storage and secure boot, along with an automatic thermal shutdown mechanism to protect device integrity during extended operation. These features ensure both data security and hardware reliability in demanding deployment environments. Available from us with full technical support for security configuration and monitoring.
What are the operating temperature and environmental specifications for this access point?
The HPE Aruba JZ345A operates reliably in environments ranging from 0 °C to 50 °C (32 °F to 122 °F) with humidity levels between 5 % and 95 % RH, making it suitable for varied indoor and semi-outdoor hospitality installations. The compact form factor (105 × 40 × 153 mm) and lightweight design (500 g) simplify mounting and deployment. Visit barcodesinc.com to explore mounting options and environmental protection accessories for your deployment.
