What are the wireless throughput speeds and performance capabilities of the HPE Aruba R8N01A AP-503R?
The HPE Aruba R8N01A delivers up to 1.49 Gbps aggregate throughput across dual 2×2:2 radios operating on 2.4 GHz and 5 GHz bands. The 2.4 GHz radio supports up to 574 Mbps with 802.11ax HE40 clients, while performance is optimized through OFDMA, bidirectional MU-MIMO, and Target Wake Time (TWT) technology for high-density deployments and battery-efficient IoT device operation.
What connectivity and backhaul options does this access point provide?
The AP-503R includes three 1 GbE ports (one uplink and two PoE-PSE ports for powering downstream devices), USB-C power input, a USB-A host port, and an optional USB LTE Cat 12 modem for cellular backhaul failover. This flexible connectivity supports both wired and wireless backhaul configurations, making it ideal for remote and branch office deployments where redundancy is critical.
Is the HPE Aruba R8N01A suitable for telework and small-branch environments?
Yes, the AP-503R is specifically designed for telework and small-branch sites with its sleek desktop form factor and enterprise-grade Wi-Fi 6 capabilities. Its low idle power consumption (4.0 W) and maximum power draw of 15.4 W make it energy-efficient, while Zero Touch Provisioning and Aruba Central cloud management enable fast, simplified deployments in distributed environments.
What security features are included in the HPE Aruba R8N01A?
The AP-503R provides comprehensive security including WPA3 encryption, Enhanced Open (OWE) for guest networks, Dynamic Segmentation for traffic isolation, and a Trusted Platform Module (TPM) for secure credential storage. These enterprise-grade security features ensure protected deployments across all network access scenarios, from corporate users to guest connectivity.
What are the environmental operating conditions and physical specifications?
The AP-503R operates reliably in environments ranging from 0°C to 50°C with 5% to 93% relative humidity, making it suitable for various indoor locations. It features integrated omni-directional antennas with peak gains of 3.9 dBi at 2.4 GHz and 5.1 dBi at 5 GHz, along with standard interfaces including three RJ-45 ports, USB-A, USB-C, micro-USB console, and Kensington security slot.
Can I use the HPE Aruba R8N01A with existing Aruba management platforms?
Yes, the AP-503R integrates seamlessly with Aruba Central cloud management for centralized configuration, monitoring, and troubleshooting across your deployment. The access point supports automated provisioning through Zero Touch Provisioning, enabling rapid scaling of your wireless network without manual configuration. Contact us today to discuss integration with your existing Aruba infrastructure.
