Release Year:
2024
Dell YMPW9 Workstation PC
Part Number:
YMPW9
Model:
Parts
Dell Misc Parts ACCESSORIES & MISC. ITEMS Model Overview
Products and parts from Dell.
Dell YMPW9 Workstation PC Overview
Smart performance and design
An intelligent, performance-optimized, space-saving small form factor.
Technical Information
Processor
Processor Type:
Core i7
Processor Generation:
14th Gen
Processor Model:
i7-14700
Processor Core:
Icosa-core (20 Core)
Processor Threads:
28
Processor Speed:
2.10 GHz
vPro Technology:
Yes
Chipset
Chipset Manufacturer:
Intel
Chipset Model:
W680
Memory
Standard Memory:
16 GB
Maximum Memory Supported:
64 GB
Memory Technology:
DDR5 SDRAM
Total Number of Memory Slots:
2
Error Checking:
Non-ECC
Memory Configuration:
2 x 8GB
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
512 GB
Solid State Drive Interface:
PCI Express NVMe 4.0
Optical Drive Type:
DVD-Writer
Controllers
Controller Type:
- Serial ATA/600
- NVMe
RAID Supported:
No
Display & Graphics
Graphics Memory Capacity:
4 GB
Graphics Memory Accessibility:
Dedicated
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Wireless LAN:
No
Interfaces/Ports
Total Number of USB Ports:
10
Number of USB 2.0 Ports:
4
Number of USB 3.2 Gen 1 Ports:
3
Number of USB 3.2 Gen 2 Ports:
2
USB Type-C:
Yes
USB Type-C Detail:
One USB 3.2 Gen 2x2 Type-C port
DisplayPort:
Yes
Mini DisplayPort:
Yes
Number of Mini DisplayPort:
4
Number of HDMI Outputs:
0
Number Of Ethernet Ports:
1
Number of DisplayPort Outputs:
3
Optional Ports:
1 Optional video port (HDMI 2.0b /Displayport 1.4a (HBR3)/VGA/USB Type-C with DisplayPort Alt mode) 1 Optional Serial/PS2 port
Details regarding optional ports aggregated from the information available for this product's family/series
Input Devices
Keyboard Localization:
English (US)
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English/French/Spanish
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Maximum Power Supply Wattage:
300 W
Frequency:
- 47 Hz
- 63 Hz
Physical Characteristics
Color Family:
Black
Product Color:
Black
Form Factor:
Small Form Factor
Height:
11.4"
Width:
3.6"
Depth:
11.5"
Weight (Approximate):
11.77 lb
Miscellaneous
Package Contents:
- Precision 3460 Small Form Factor
- Keyboard
- Mouse
- System Power Cord C13 (US 125V, 15A)
- Safety/Environment and Regulatory Guide (English/French Multi-language)
- Quick Setup Guide, Precision 3460
- 4 mDP to DP Adapters
Energy Star:
Yes
Country of Origin:
Mexico
Environmentally Friendly:
Yes
Environmental Certification:
Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:
3Y Basic Onsite Service after remote diagnosis with Hardware-Only Support-Disti SnS
Item Numbers
GTIN:
0884116471356
UPC:
884116471356
EAN:
0884116471356
UNSPSC:
56112002
Frequently Asked Questions
What processor does the Dell YMPW9 Precision 3460 Workstation include?
The Dell Precision 3460 features a 14th Generation Intel Core i7-14700 processor with vPro Technology, delivering enterprise-grade performance and advanced security management capabilities. This processor is ideal for professional workloads requiring reliable computing power in a compact small form factor design.
How much memory and storage does this Dell workstation support?
The Dell YMPW9 comes configured with 16 GB of RAM and a 512 GB SSD for fast boot and application performance. The system supports DDR3 SDRAM with multiple capacity options and includes a Serial ATA/600 controller along with NVMe support for flexible storage expansion.
What graphics capabilities does the Dell Precision 3460 offer?
This workstation includes 4 GB of dedicated graphics memory, providing robust visual performance for design, engineering, and content creation applications. The Intel W680 chipset architecture supports professional-grade graphics processing suitable for demanding visualization tasks.
What connectivity and security features are included?
The Dell YMPW9 provides Gigabit Ethernet connectivity and includes an English (US) keyboard with integrated security features. The system supports optional SmartCard readers, fingerprint authentication, and TPM 1.2 for enhanced data protection in enterprise environments.
Is this workstation suitable for warehouse and logistics operations?
Yes, the Dell Precision 3460's compact small form factor, Windows 11 Pro operating system, and robust connectivity make it suitable for logistics management and warehouse operations. Its professional-grade build quality and security features support mission-critical AIDC and inventory management applications.
What operating system and warranty does the Dell YMPW9 include?
The Dell Precision 3460 ships with Windows 11 Pro and includes a 1-year limited warranty covering parts, labor, and on-site repair. Contact us today at barcodesinc.com to learn about extended warranty options and support plans available from our team.
